Denon CEOL RCD-N11DAB User Manual

Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
.
Internet
Modem
PC
Router
To WAN side
To LAN port
To LAN port
LAN port/
Ethernet
connector
LAN port/
Ethernet
connector
NAS
(Network Attached
Storage)
Contents
Connections Playback Settings Tips Appendix
27
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N11DAB Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Apple docking	-
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical in	2
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	- W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Signal-to-Noise Ratio (SNR)	74 dB
Total Harmonic Distortion (THD)	0.7 %
Volume control	Touch
Supported radio bands	AM, DAB, DAB+, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Power source	AC
Input voltage	230 V
Input frequency	50/60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Package type	Box
Package depth	390 mm
Package width	380 mm
Package height	513 mm
Package weight	6000 g
Main unit weight	3400 g
Main unit dimensions (WxDxH)	280 x 305 x 108 mm
