Automatically presetting FM stations
(Auto Preset)
You can automatically register all FM stations that can be received to the
preset list. Up to 50 stations can be registered.
1
Press OPTION during FM reception.
An option menu is displayed.
2
Use ui to select “Auto Preset Memory”, then press
ENTER.
3
Use ui to select “Start”, then press ENTER.
The unit starts to tune in to radio stations automatically and preset
them.
0
When presetting is completed, “Complete!!” is displayed.
0
To stop auto tuning, press 2.
0
Broadcast stations whose antenna signals are weak cannot be preset
automatically. If you wish to preset such stations, tune them in manually.
0
Additional stations cannot be registered to the preset list after 50 stations are
registered.
0
DAB stations cannot be automatically preset.
Listening to stations registered in the
preset list
1
Press OPTION during reception of a station.
An option menu is displayed.
2
Use ui to select “Preset List”, then press ENTER.
3
Use ui and select the radio station that you want to
listen to, then press ENTER.
4
Use ui to select “Play Now”, then press ENTER.
0
You can select the station you want to listen to from the preset list by pressing 0-9
and +10.
0
You can switch between preset stations by pressing CH+, CH- or o p.
Contents
Connections Playback Settings Tips Appendix
62
Front/Top
panel
Rear panel
Remote control
unit
Index

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon CEOL RCD-N11DAB and is the answer not in the manual?

Denon CEOL RCD-N11DAB Specifications

General IconGeneral
TypeHome audio micro system
Cassette deckNo
Product colorBlack
Optical disc playerYes
Apple docking-
Headphone outputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical in2
Channels quantity2 channels
Disc types supportedCD, CD-R, CD-RW
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Impedance6 Ω
Speaker type2-way
Frequency range50 - 20000 Hz
RMS rated power- W
Woofer diameter120 mm
Tweeter diameter30 mm
Signal-to-Noise Ratio (SNR)74 dB
Total Harmonic Distortion (THD)0.7 %
Volume controlTouch
Supported radio bandsAM, DAB, DAB+, FM
Internet radio services supportedAmazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Power sourceAC
Input voltage230 V
Input frequency50/60 Hz
Power consumption (standby)0.4 W
Power consumption (typical)55 W
Display typeOLED
Weight and Dimensions IconWeight and Dimensions
Package typeBox
Package depth390 mm
Package width380 mm
Package height513 mm
Package weight6000 g
Main unit weight3400 g
Main unit dimensions (WxDxH)280 x 305 x 108 mm
