(8)
Adjustment
of
Tracking
Gain
a)
Adjust
it
in
the
same
condition
as
to
focus
gain,
push
play
button
PLAY)
to
activate
all
servo
for
adjustment
except
the
measuring
equipment
connections.
(2)
Audio
oscillator
should
be
connected
while
the
servo
is
in
operation.
If
the
connection
is
made
before
servo
operation,
causing
mis-operation.
If
the
connection
is
made
in
failure,
disconnect
oscillator,
push
stop
button
(™
STOP)
to
stop
all
operations,
and
follow
the
steps
from
the.
begin-
ning.
8)
Connection
of
measuring
equipment.
@
Connect
the
respective
measuring
equipments
to
the
test
point
TP-201
of
servo
main
P.W.B.
(KU-6040)
as
illustration
shows.
TEOX
Pin
@
of
TP-201
TEIX
Pin
©
of
TP-201
©
GND
Pin
@
of
TP-201
0
%
TEO:
Track
Error
Out
TEI:
Track
Error
In
(9)
Check
of
Tracking
Offset
@
Check
the
adjustment
performed
in
the
previous
column
(5).
@
Push
stop
button
(™STOP)
to
stop
disc
revolution.
@
With
a
sufficient
interval
of
time
in
between,
push
play
button
PLAY)
twice
and
check
that
the
disc
starts
to
run.
Note:
The
microcomputer
employed
in
the
unit
sometimes
does
not
accept
button
opera-
tion.
If
so,
push
the
button
again.
Confirm
that
“2”
on
the
calendar
fails.
@)
Adjustment
@
Set
the
output
of
audio
oscillator
to
1.8
kHz
+
120
Hz,
2
Vp-p
+
0.1
V.
®
Connect
two
filters
as
per
illustration.
@
Select
oscilloscope
input
to
X-Y
mode
so
to
observe
Lissajous
waveform.
(Select
DC
range
both
X
and
Y
inputs.)
e@
Adjust
VR-202
and
obtain
Lissajous
waveform
symmetric
to
X
and
Y
axes.
The
waveform
is
the
same
as
focus
gain
adjustment.
Oscilloscope
Audio
Oscillator
C_J
Set
to
1.8
kHz,
2Vp-p
Frequency
Counter
@
Observe
a
waveform
and
check
that
the
height
of
upper
and
lower
waveform
are
even
to
the
base
line.
(Reference
value:
Difference
of
height
between
two
is
5%
or
less.)
@
If
the
difference
is
beyond
the
value,
adjust
VR-401.
©
@
That
is
all
to
complete
adjustments.
@
Remove
the
signal
pick-up
connector
with
wires
from
TP-401
of
mechanism
unit
P.W.B.
(KU-
6050)
and
TP-201
of
servo
main
P.W.B.
(KU-
6040).
