Denon DN-C635 - PARTS LIST OF EXPLODED VIEW

38
38DN-C635
PARTS LIST OF EXPLODED VIEW
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A./Canada model E2K: Korea model
E2: Europe model JP: Japan model
Ref.No. Part No. Part Name Remarks Q'ty New
1 00DGU-3510 MAIN P.W.B. UNIT ASS'Y 1
2 00DGU-3511 DISPLAY P.W.B. UNIT ASS'Y for E3 1
2 00DGU-3511A DISPLAY P.W.B. UNIT ASS'Y for E2, E2K 1
2 00DGU-3511B DISPLAY P.W.B. UNIT ASS'Y for JP 1
2-1 FLT UNIT
2-2 SLIDE VR. UNIT
2-3 H/P UNIT
2-4 PSW UNIT
2-5 XLR UNIT
2-6 TRANS UNIT
3 00D 411 1389 108 CHASSIS 1 *
4 00D 461 0706 127 FOOT SHEET 2
5 00D 412 5001 003 TRANS BRACKET 1
6 00D 411 1983 106 MECHA BASE 1
7 00D 412 4069 101 P.W.B BRACKET 2
8 00D 105 1429 037 BACK PANEL for E3 1 *
8 00D 105 1429 011 BACK PANEL for E2, E2K 1 *
8 00D 105 1429 040 BACK PANEL for JP 1 *
! 9 00D 233 6552 000 POWER TRANS 1 *
10 00D 412 2814 015 CARD SPACER (L=14) 3
11 00D 412 4812 015 SPRING PLATE 1
12 00D 441 1980 003 EARTH PLATE 1
! 13 00D 206 2155 001 AC CORD W/CON.E3 for E3 1
! 13 00D 206 2089 106 AC CORD W/CON.E2 for E2 1
! 13 00D 206 2178 004 KOREA AC CORD VH for E2K 1
! 13 00D 206 2085 003 AC CORD W/CON.DOM for JP 1
14 00D 445 0084 009 CORD BUSH for E3 1
14 00D 445 0056 008 CORD BUSH for E2, E2K, JP 1
15 00D 337 0100 006 CD MECHA(CD11FT3NF) 1
16 00D 009 0241 002 16P FFC CABLE 1
17 00D 203 8305 034 5P KR-KR CON.CORD 1
18 00D 204 0307 091 6P KR-KR CON.CORD 1
19 00D 441 1981 002 FRONT SUB PANEL 1 *
20 00D 144 2829 000 FRONT PANEL 1 *
21 00D 146 1661 016 POWER SW PROTECTOR 1
22 00D 143 1166 004 WINDOW 1 *
23 00D 146 1371 005 LED WINDOW 4
24 00D 119 0099 111 RUBBER KEY (A) 1 *
25 00D 119 0100 110 RUBBER KEY (B) 1 *
26 00D 461 1140 025 PAD 1
27 00D 412 4425 004 H/P BRACKET 1
28 00D 445 8028 009 CORD HOLDER 2
29 00D 009 0162 039 23P FFC CABLE 1 *
30 00D 477 0224 031 SP WASHER 4
31 00D 415 0816 001 PCB COVER 1
32 00D 479 0003 025 PUSH RIVET 2
33 00D 461 0740 002 SHEET 2
34 00D 203 5307 022 3P VH-VH CON.CORD 1
35 00D 113 1357 207 P.SW KNOB 1
