5
DN-D6000
4. Main P.W.B.
(1) Short-circuit the short land above.
(2) Remove a screw 52 and a screw 54.
(3) Disconnect FFC cable and FPC cable.
(4) Detach Main P.W.B.
Note:
z Do not pull out aslant to prevent FFC cable damage.
5. CD Mecha
(1) Remove 2 screws 51 and pull out Main Pwb Bracket.
(2) Remove 2 screws 53 and pull out Disc Guide.
FFC Cable
Short land for laser diode
54
Main Pwb
52
FPC Cable
53
53
Main Pwb Bracket
Disc Guide
CD Mecha
51
51
