14
DN-S1000
80 PD4
KIN0 I - Pu - H DNS1000: Key scan input signal 0
EJECT I - Pu - H DND6000: Disc eject button input signal
81 PD5
KIN1 I - Pu - H DNS1000: Key scan input signal 1
CDSEL I - Pu - H DND6000: CD mecha. Select H: CD1, L: CD2
82 P90 KIN2 I - Pu - H DNS1000: Key scan input signal 2
83 P91 KIN3 I - Pu - H DNS1000: Key scan input signal 3
84 P92 _LSSW I - iPu - - Disc input detect SW L: Disc in
85 P93 _PISW I - iPu - - Inner switch L: Switch ON
86 Vref+ Vref+ - - - - - Analog ref. V for A/D conversion, +3.3V
87 AVDD AVDD - - - - - Power (+3.3V)
88 P94 DSENS I - iPu - - Disc sensor 12/8 cm disc detect L: 12cm disc
89 P95 _CSW I - iPu - - Loading switch L: Switch ON
90 P96,DAC2 DSPF0 O - - L - Flag 0 for DSP (RESERVE)
91 P97,DAC3 _DSPRES O - Pd L L DSP reset signal L: RESET
92 PC6,BREQ_ _BREQ I - Pu - H Bus request signal
93 PC7,BRACK_ _BRACK O - Pu H H Bus request accept signal
94 WEL_ WE_ O - Pu - H Ext. memory write enable (Lower 8 bit)
95 P51 _BOOT O - Pu H H DSP boot start signal L: START
96 RE_ RE_ O - Pu - H Ext. memory read enable
97 CS2_ CS2_ O - - - - Ext. memory chip select 2 (Not used)
98 VDD VDD - - - - - Power (+3.3V)
99 VSS VSS - - - - - GND
100 P54,BSTRE FPLAY I - Pu H H Fader start PLAY input
101 P55,WR_ FCUE I - Pu H H Fader start CUE input
102 CS3_ CS3_ O - - - - Not used
103 A00 A00 O - - - - Ext. memory address 0 (16 bit bus select : not used)
104 A01 A01 O - - - - Ext. memory address 1 (16 bit bus select : not used)
105 A02 A02 O - - - - Ext. memory address 2 (16 bit bus select : not used)
106 A03 A03 O - - - - Ext. memory address 3 (16 bit bus select : not used)
107 A04 A04 O - - - - Ext. memory address 4 (16 bit bus select : not used)
108 A05 A05 O - - - - Ext. memory address 5 (16 bit bus select : not used)
109 A06 A06 O - - - - Ext. memory address 6 (16 bit bus select : not used)
110 A07 A07 O - - - - Ext. memory address 7 (16 bit bus select : not used)
111 A08 A08 O - - - - Ext. memory address 8 (16 bit bus select : not used)
112 PD6 DSPF1 O - - L - Flag 1 for DSP (RESERVE)
113 PD7,TM7IO DISCPB_ I - iPu - - Disc for scratch pulse B reverse phase count input
114 A09 A09 O - - - - Ext. memory address 9 (16 bit bus select : not used)
115 A10 A10 O - - - - Ext. memory address 10 (16 bit bus select : not used)
116 A11 A11 O - - - - Ext. memory address 11 (16 bit bus select : not used)
117 A12 A12 O - - - - Ext. memory address 12 (16 bit bus select : not used)
118 A13 A13 O - - - - Ext. memory address 13 (16 bit bus select : not used)
119 VDD VDD - - - - - Power (+3.3V)
120 PC4 DSPF2 O - - L - Flag 1 for DSP (RESERVE)
121 A14 A14 O - - - - Ext. memory address 14 (16 bit bus select : not used)
122 A15 A15 O - - - - Ext. memory address 15 (16 bit bus select : not used)
123 A16 A16 O - - - - Ext. memory address 16 (16 bit bus select : not used)
124 A17 A17 O - - - - Ext. memory address 17 (16 bit bus select : not used)
125 A18 A18 O - - - - Ext. memory address 18 (16 bit bus select : not used)
126 A19 A19 O - Pd - - Ext. memory address 19 (16 bit bus select : not used)
127 A20 A20 O - - - - Ext. memory address 20 (16 bit bus select : not used)
128 A21 A21 O - - - - Ext. memory address 21 (16 bit bus select : not used)
Pin
No.
Pin Name Simbol I/O DET Ext Ini Res Function
