13
DN-S1000
29 VDD VDD - - - - - Power (+3.3V)
30 OSCI OSCI I - - - - Oscillation input, 32.0MHz
31 OSCO OSCO O - - - - Oscillation output
32 VSS VSS - - - - - GND
33 P57,BOSC RESERVE O - - L - TP
34 PC5,NMI_ NMI I - - - - Connect to Power
35 RST_ RST_ I - - - - µcom reset
36 PC0 _MUTE O - Pd L L Mute signal (L: Mute)
37 P76 RESERVE O - - L - TP
38 P60,IRQ0 DTIME I - Pu H H X2: Clock for playback interrupt input / X1: LRCK
39 P61,IRQ1 BLKCK I - iPu - - Sub cord clock interrupt
40 P62,IRQ2,TM10IOA LOAD O - - Hi-Z - Disc roading, eject signal (PWM output)
41 P63,IRQ3,TM10IOB DQSY I - iPu - - CD-TEXT DQSY interrupt
42 P64,IRQ4 DTIMES I - Pu H H X2: Sampler clock for playback interrupt input / X1:
43 P65,IRQ5,TM12IOA DISCA I - - - - Disc for scratch pulse A count input
44 P66,IRQ6 DISCDIR I - (Pu) H H Scratch disc detect round direction interrupt input
45 P67,IRQ7 DISCINT I - (Pu) H H Disc round start interrupt input
46 P70,TM13IOB DISCPA I - (Pu) H H Pulse width for scratch disc gauge input
47 P71 ML O - iPu Hi-Z - D/A interface scratch
48 PD2,DMAACK0_ CHGOFT O - Pu L H Off-track signal (Transistor drive)
49 PD3,TM3IO DISCPA_ I - - - - Disc for scratch pulse A reverse phase count input
50 VDD VDD - - - - - Power (+3.3V)
51 P77 RESERVE O - - L - TP
52 P72,TM14IOB DISCPB I - - - - Disc for scratch pulse B count input
53 P73 _NRES O - Pd L L IC reset signal
54 P74 MLD O - - H - Servo DSP interface latch
55 P75,TM12IOB DCLK I - - - - Clock input for pulse width gauge for disc (5.6MHz)
56 PA0,SBI0 STAT I - iPu - - Servo DSP interface receive (clock sync)
57 PA1,SBO0 MDAT O - - H - Servo DSP interface send (clock sync)
58 PA2,SBT0 MCLK O - - H - Servo DSP interface clock (clock sync)
59 PA3,SBI1 RXDCD I - Pu - - Mecha. between interface receive (UART)
60 PA4,SBO1
LEDCLK1 O - Pu H H DNS1000: LED driver (BU2090) clock 1 for data send
TXDCD O - Pu H - DND6000: Mecha. between interface receive (UART)
61 PA5,SBT1 _DSTBY O - Pd L L Driver standby signal L: standby
62 PB0,SBI2 DSPTXD(RXD) I - Pu - - DSP interface receive (UART)
63 PB1,SBO2 DSPRXD(TXD) O - Pu H H DSP interface send (UART)
64 PB2,SBT2 _FLCS O - Pu H H DNS1000: FLT driver enable signal
65 PB3,SBI3 RXDRC I - - - - DND6000: RCD 60 interface receive (UART)
66 PB4,SBO3
PDATA O - Pu H -
DNS1000: FLT driver (M66005A) data, LED driver data (clock sync)
TXDRC O - Pu H - DND6000: RCD interface send (UART)
67 PB5,SBT3
FLCLK O - - H -
DNS1000: FLT driver (M66005A) clock for data send (clock sync)
RESERVE O - - H - DND6000: RESERVE
68 VDD VDD - - - - - Power (+3.3V)
69 VSS VSS - - - - - GND
70 AVSS AVSS - - - - - Analog ref. GND for A/D conversion, GND
71 Vref- Vref- - - - - - Analog ref. V for A/D conversion, GND
72 P80 _FLRES O - Pd L L DNS1000: FLT driver (M66005A) reset signal
73 P81 CSKSEL O - Pd H L L: Servo DSP D/A clock select
74 P82
LEDCLK2 O - Pu H H DNS1000: LED driver (BU2090) clock 2 for data send
RESERVE I - Pu - - DND6000: RESERVE (connect to RXDCD)
75 P83 SEL_A O - - L - DNS1000: Key scan output select signal A
76 P84 SEL_B O - - L - DNS1000: Key scan output select signal B
77 P85 SEL_C O - - L - DNS1000: Key scan output select signal C
78 P86,AD06 PITCH I - - - - DNS1000: Slid VR for pitch data input
79 P87,AD07 PITCHC I - - - - DNS1000: Slid VR for pitch center value data input
Pin
No.
Pin Name Simbol I/O DET Ext Ini Res Function
