Function
I/O
Pin
No.
Pin Name
Symbol
DET Ext Ini Res
26 PC3 MUTE O — Pu H H Mute signal (H: Mute)
27 XI XI I — — — — Oscillation input
28 XO XO O — — — — Oscillation output
29 VDD VDD — — — — — Power (+3.3V)
30 OSCI OSCI I — — — — Oscillation input, 34.0MHz
31 OSCO OSCO O — — — — Oscillation output
32 VSS VSS — — — — — GND
33 P57,BOSC TEST
NMI
I— Pu H — P.W.B. check mode IN
Connect to Power
34 PC5,NMI I — — ——
35 RST_ RST_ I — —— — µcom reset
36 PC0 YMCLK O — — H — Clock for SM5902(DOUT)/PCM1608(D/A) data
37 P76 MDO O — Pd — L PCM1608(D/A) input data
38 P60,IRQ0 DTIMA I — Pu H H Main playback clock input
39 P61,IRQ1 DTIMB I — Pu H H Monitor playback clock input
40 P62,IRQ2,TM10IOA TABLE I — (Pu) H H Clock pulse input for platter
41 P63,IRQ3,TM10IOA CLK4M I — — — — Clock pulse input for platter
42 P64,IRQ4 ATANS_ I — (Pu) — H ATAPI µcom serial interface
43 P65,IRQ5,TM12IOA DISCPA I — (Pu) H H Clock pulse input for scratch disc
44 P66,IRQ6 DISCDIR I — (Pu) H H Direction pulse input for scratch disc
Start pulse input for scratch disc
45 P67,IRQ7 DISCINT I — (Pu) H H
46 P70,TM13IOB DISCA I — ——— SCRATCH for DISC pulse A count input
47 P71 YMDATA O — — H — SM5902(DOUT)/PCM1608(D/A) output data
48 PD2,DMAACK0_ NRES_ O — Pd L L SM5902(DOUT)/PCM1608(D/A) reset signal
Clock invert pulse input for scratch disc
49 PD3,TM3IO DISCPA_ I — — —
50 VDD VDD — — — — — P
—
ower (+3.3V)
51 P77 ZSENCE2 I — — — — SM5902 µcom interface status for MONITOR
52 P72,TM14IOB DISCPB I — — — — SCRATCH for DISC pulse B count input
53 P73 YMLD1_ O — — H — SM5902(DOUT) chip select for MAIN
54 P74 YMLD2_ O — — H — SM5902(DOUT) chip select for MONITOR
55 P75,TM12IOB CLK4M I — — — — Clock pulse input for disc
56 PA0,SBI0 RXD1 I — (Pu) — H Data receive from PANEL
57 PA1,SBO0 TXD1 O — Pu H H Data send to PANEL (PU µcom specify)
58 PA2,SBT0 MCMD_ O — Pu H H ATAPI µcom serial interface (PU µcom specify)
59 PA3,SBI1 X'RXDOUT I — (Pd) — H Data receive from X'EFFECT OUT
60 PA4,SBO1 X'TXDOUT
ZSENCE1
O — Pu H H Data send to X'EFFECT OUT
61 PA5 I — — — — SM5902 µcom interface status for MAIN
62 PB0,SBI2 X’RXD IN I — (Pd) — H Data receive from X’EFFECT IN
63 PB1,SBO2 X’TXD IN O — Pu H H Data send to X’EFFECT IN
64 PB2 APRES_ O — Pd L L ATAPI µcom reset signal
65 PB3,SBI3 ATDATA I — (Pu) — H ATAPI µcom serial receive signal
66 PB4,SBO3 MDATA O — — H — ATAPI µcom serial send signal
67 PB5,SBT3 MCLK O — — H — ATAPI µcom serial send/receive clock
68 VDD VDD — — — — — Power (+3.3V)
69 VSS VSS — — — — — GND
70 AVSS AVSS — — — — — Analog ref. GND for A/D conversion, GND
71 Vref Vref — — — — — Analog ref. V for A/D conversion, GND
72 P80 DFLG2 I/O — Pu — H DSP gener al flag 2
73 P81 DFLG1 I/O — Pu — H DSP gener al flag 1
74 P82 DR_/W1 O — — H — DSP interf ace send/receive select signal
75 P83 DACK_ I — Pu H H DSP interf ace ACK
76 P84 DBSY_ I — Pu H H DSP interf ace busy signal
77 P85 DFLG0 I/O — Pu — H DSP gener al flag 0
78 P86 DREQ_ O — Pu H H
HH
DSP interf ace request signal
79 P87 FPLAY1 I — Main fader start PLAY input
80 PD4 FCUE1 I — (Pu) H H Main fader start CUE input
81 PD5 FPLAY2 I — (Pu)
(Pu)
H H Monitor fader start PLAY input
82 P90 FCUE2 I — H Monitor fader start CUE input
83 P91 RESERVE O — — L —
84 P92 PNLRST — — Pd L L Panel µcom reset signal (L:Reset)
85 P93 APOWER O — Pd L L Analog output voltage ON/OFF (L:OFF)
86 Vref+ Vref+ — — — — — Analog ref. V for A/D conversion, +3.3V
87 AVDD AVDD — — — — — Power (+3.3V)
H
(Pu)
