Denon DVD-1920 - Page 13

13
DVD-1920/756
[6] Rear Panel
(S-5)
(S-3)
(S-3)
(S-4)
(S-3)
Fig. D4
(S-6A)
(S-6B)
(S-6)
(S-7)
[9] Jack PCB
Holder
[8] 5.1ch
Amp CBA
[7] DVD Main CBA Unit
CN401
CN301
(L-5)
A
Fig. D5
View for A
Short the three short lands by soldering.
(Either of two places.)
Connector
CNS01
CN7101
CN201
CN601
Fig. D6
[10] DVD
Mechanism
(S-8)
(S-8)
[12] AV CBA
[11] LED CBA
(S-9)
(S-9)
(S-10)
CN2102
Fig. D7
