35
DVD-1920/756
IC101 Voltage Chart
PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY
1 3.4 3.4 33 ~ ~ 65 ----- ----- 97 0
2 0 0 34 0 0 663.43.498 0
3 3.53.5353.53.5673.43.499 0
4 3.5 3.5 36 ~ ~ 68 0 0 100 0
5 0 037~ ~693.53.51010
6 ----- ----- 38 ~ ~ 70 3.6 3.4 102 3.5
7 3.3 0.8 39 ~ ~ 71 3.2 3.2 103 0.9
8 3.53.540 ~ ~ 723.50.1104 0
9 0 041~ ~733.53.51052.4
10 ----- ----- 42 ~ ~ 74 3.4 3.4 106 1.9
11 ----- ----- 43 ~ ~ 75 3.4 3.4 107 0.4
12 ----- ----- 44 0 0 76 3.2 3.2 108 0
13 0.1 0.1 45 1.3 1.3 77 3.5 3.5 109 1.7
14 ----- ----- 46 ~ ~ 78 3.4 3.4 110 3.5
15 3.4 3.4 47 ~ ~ 79 ----- ----- 111 -----
16 0 0 48 ~ ~ 80 3.2 3.2 112 -----
17 3.5 3.5 49 ~ ~ 81 3.5 3.5 113 1.9
18 ~ ~ 50 ~ ~ 82 0 0 114 1.9
19 2.4 2.8 51 ~ ~ 83 1.3 1.3 115 1.7
20 2.4 2.8 52 0 0 84 3.3 3.3 116 1.7
21 0 0 53 3.5 3.5 85 1.4 2.7 117 1.7
22 1.3 1.3 54 ~ ~ 86 0.1 0.1 118 1.7
23 ~ ~ 55 3.4 3.4 87 0 0 119 3.5
24 ~ ~ 56 ~ ~ 88 3.4 0 120 2.0
25 ~ ~ 57 ~ ~ 89 3.4 3.5 121 1.5
26 ~ ~ 58 ~ ~ 90 2.3 1.8 122 0
27 ~ ~ 59 ~ ~ 91 1.7 1.8 123 0.3
28 ~ ~ 60 ~ ~ 92 0 0 124 1.1
29 ~ ~ 61 ~ ~ 93 3.5 3.5 125 0.3
30 ~ ~
62
~ ~ 94 0 0 126 0.1
31 ~ ~
63
~ ~ 95 0 0 127 2.3
32 ~ ~
64
~ ~ 96 0 0 128 1.7
STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP
0 129 2.3 2.3 161 0 0 193 3.2 3.2 225 1.9 1.9
0 130 2.3 2.3 162 1.7 1.7 194 3.2 3.2 226 0 0
0 131 2.3 2.3 163 1.7 1.7 195 1.7 1.7 227 3.2 3.2
0 132 2.4 2.3 164 0 0 196 0 0 228 3.3 3.3
0 133 2.4 2.4 165 1.3 1.3 197 3.5 3.5 229 3.0 3.0
3.5 134 2.4 2.4 166 3.2 3.2 198 ~ ~ 230 ~ ~
0.8 135 2.3 2.3 167 3.2 3.2 199 ~ ~ 231 1.6 1.6
0 136 2.3 2.3 168 0 0 200 ~ ~ 232 ~ ~
2.4 137 2.3 2.3 169 0 0 201 ~ ~ 233 0 0
1.9 138 2.3 2.3 170 0 0 202 ~ ~ 234 1.3 1.3
0.3 139 2.1 1.7 171 0 0 203 ~ ~ 235 1.4 1.4
0 140 1.7 1.7 172 0 0 204 3.5 3.5 236 ~ ~
1.7 141 1.7 1.7 173 3.2 3.2 205 0 0 237 ~ ~
3.5 142 1.7 1.7 174 0 0 206 ~ ~ 238 0 0
----- 143 0 0 175 3.5 3.5 207 ~ ~ 239 3.4 3.4
----- 144 1.7 1.7 176 1.3 1.3 208 ~ ~ 240 ~ ~
1.9 145 1.7 1.7 177 1.3 1.3 209 ~ ~ 241 ~ ~
1.9 146 3.5 3.5 178 1.3 1.3 210 ~ ~ 242 ~ ~
1.7 147 ----- ----- 179 1.5 1.5 211 ~ ~ 243 ~ ~
1.7 148 ----- ----- 180 1.0 1.0 212 ~ ~ 244 ~ ~
1.7 149 ----- ----- 181 1.0 1.0 213 ~ ~ 245 ~ ~
1.7 150 3.5 3.5 182 1.0 1.0 214 3.5 3.5 246 ~ ~
3.5 151 2.2 2.2 183 1.0 1.0 215 0 0 247 ~ ~
2.0 152 1.4 1.3 184 3.5 3.5 216 ~ ~ 248 0 0
1.5 153 1.4 1.3 185 0 0 217 ~ ~ 249 3.4 3.4
0 154 2.2 2.2 186 1.5 1.5 218 1.3 1.3 250 ----- -----
0.1 155 0 0 187 3.3 3.3 219 2.4 2.1 251 ----- -----
0 156 0.6 0.6 188 3.3 3.3 220 2.4 2.1 252 3.4 3.4
0.1 157 0.9 0.9 189 0 0 221 3.3 3.3 253 2.8 2.8
0.1 158 3.5 3.5 190 1.6 1.6 222 0 0 254 3.3 3.3
2.3 159 0 0 191 3.3 3.3 223 1.6 1.6 255 3.4 3.4
1.7 160 3.5 3.5 192 3.2 3.2 224 3.5 3.5 256 3.4 3.4
~ : Voltage is not consistent ----- : Not used Unit : Volts
