Denon DVD-758 - Disassembly Flowchart; Disassembly Method

9
DVD-1940CI/758
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
Note:
(1) Identification (location) No. of parts in the figures
(2) Name of the part
(3) Figure Number for reference
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to “Reference Notes.”
About tightening screws
When tightening screws, tighten them with the
following torque.
ID/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Desolder
Note
[1] Top Cover D1 5(S-1) ---
[2] Front Unit D2
*4(L-1), *2(L-2),
*3(L-3), *CN2001
1
[3] Tray Panel D2 *2(L-4) 1
[4]
Function
CBA
D3 5(S-2) ---
[5]
Front
Assembly
D3 ---------- ---
[6]
Reinforce
Plate
D4 2(S-3) ---
[7] Rear Panel D4
9(S-4), (S-5), (S-6),
2(S-7)
4
[8]
DVD Main
CBA Unit
D5
3(S-8), *CN201,
*CN301, *CN401,
*CN601, *CNS01,
*CNF02
2
4
[9]
Interface
CBA
D6 (S-9) ---
[1] Top Cover
[5] Front Assembly
[2] Front Unit
[3] Tray Panel
[6] Reinforce Plate
[7] Rear Panel
[16] Loader Base
[18] Main PCB Holder
[8] DVD Main CBA Unit
[13] DVD Mechanism
[17] Power PCB Holder
[14] LED CBA
[4] Function CBA
[11] 5.1ch Amp CBA
[12] Jack PCB Holder
[9] Interface CBA
[10] D Sub Holder
[15] AV CBA
[10]
D Sub
Holder
D6 (S-10) ---
[11]
5.1ch Amp
CBA
D6
(S-11), 2(L-5),
*CN7101
---
[12]
Jack PCB
Holder
D6 2(S-12) ---
[13]
DVD
Mechanism
D5
D7
4(S-13)
2
3
[14] LED CBA D8 *CN2102 ---
[15] AV CBA D8 4(S-14), (S-15) ---
[16]
Loader
Base
D9 4(S-16) ---
[17]
Power PCB
Holder
D9 2(S-17) ---
[18]
Main PCB
Holder
D9 (S-18) ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
Screws Torque
(S-1), (S-2), (S-3), (S-4),
(S-5), (S-6), (S-7), (S-8),
(S-9), (S-10), (S-11),
(S-12), (S-13), (S-14),
(S-15), (S-16), (S-17),
(S-18)
0.45 ± 0.05 N·m
ID/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Desolder
Note
