Denon HOME 250 Service Manual

WIRING DIAGRAM
DENONHOME250 WIRING DIAGRAM
TOUCH B'D
(CUP13087Z_1)
CN4007
FFC_40P
MAIN B'D
(CUP13088Z)
SMPS B'D
(VOP13086B_DH250_SMPS)
5P
BN6001
2P
BN6002
CN2
5P
CN2002
4P
CN2001
WFTW TW WF
2P
CN1
CN4001
B TO B 80P
5P
SUN MODULE B'D
(CUP13082Z)
CN8002
FFC_40P
CN4003
FFC_9P
J9094
FFC_9P
WJ2WJ1
Wi-Fi ANT
SPK WIRESPK WIRE
CN8007
FFC_5P
CN11
FFC_5P
COP13092B_MIC
MIC B'D AS'Y
CN8006
FFC_5P
CN11
FFC_5P
COP13092B_MIC
MIC B'D AS'Y
CN8005
FFC_8P
CN8003
FFC_8P
VUI LED B'D
(CUP13087Z_2)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
35

Denon HOME 250 Specifications

General

Product color	White
Volume control	Touch
Recommended usage	Tablet / Smartphone
Remotely operated	Yes
Remote control type	Wireless
Speaker type	-
Woofer diameter	100 mm
Tweeter diameter	19 mm
Number of drivers	4
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Number of tweeter drivers	2
RMS rated power	- W
Amplifier class	D
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Cables included	AC
Package depth	192 mm
Package width	385 mm
Package height	323 mm
Package weight	4800 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	120 mm
Width	295 mm
Height	216 mm
Weight	3700 g
