21
RCD-M35DAB/M33
48 VSS - Digital GND
49 Pi2 I General Input-2 Schmitt input
50 Pi3 I General Input-3 Schmitt input
51 Pi4 I General Input-4 Schmitt input
52 VDD - Power Supply for Digital Circuit (2.5V)
53 Pi5 I General Input-5 Schmitt input
54 TSTiN I Test Terminal (H or L fixed) Schmitt input
55 Fi2 I Flag Input-2 Schmitt input
56 VSSP - GND for VCO Circuit
57 Pdo O PLL Phase Detector Signal Output
58 Vcoi I VCO Control Voltage Input
59 VDDP - Power Supply for VCO Circuit (2.5V)
60 CKi/Cko/Po6 I/O External System Clock Input/Clock Output/General Output-6 External pull up
61 VDDX - Power supply for crystal oscillator (2.5V)
62 Xi I Crystal Oscillator Input
63 Xo O Crystal Oscillator Output
64 VSSX - GND for Crystal Oscillator
Pin
No.
Symbol I/O Description of pin function Remark
