Denon RCD-N7 Product Sheet

Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: 201-762-6500
usa.denon.com
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: 905-475-4085
ca.denon.com
18070910 A
RCD-N7 Network CD Receiver
Enjoy variety of music source
• Music files stored on a network-connected device
such as a PC or NAS
• Plays USB memory player
• Plays CD, CD-R /CD-RW (WMA or MP3)
• Listen to FM / AM
• Front panel input for any portable device (analog)
• Optical digital audio input
High-quality sound
• Integrates Denon hi- component sound engineering
into a compact size
• “Simple & straight” circuit design and minimum
signal path, to optimize sound quality
• Equipped with a high-grade amplifier, for powerful,
dynamic sound from a compact chassis
• 65 W + 65 W, high power output (4 ohms, 1 kHz)
• Optimizing Filter, to align the RCD-N7 with the
optional SC-N7 speaker system characteristics
Easy-of-Use
• Support for Wi-Fi Protected Setup (WPS), easy
to connect to wireless LAN
• Network First Setup
• Ergonomically designed remote control
• Plug ’n Play
Optional SC-N7 Speaker system
• 12 cm bass-mid driver and 2.5 cm balanced dome
tweeter
• MDF wooden cabinet
Notes:
(*1) This feature is not available in all countries.
(*2) Update distribution via network connection is slated to start around
Autumn 2010.
Main Specications
RCD-N7
Rated output power 65 W + 65 W (1 kHz, 4ohm)
FM section
Frequency range 87.5 to 107.9 MHz
AM section
Frequency range 530 to 1710 kHz
General
Power supply AC 120 V, 60 Hz
Power consumption 65 W (Standby: 0.3 W)
Dimensions (W x H x D) 11-1/32” x 4-13/32” x 11-49/64”
280 x 112 x 299 mm
Weight 9 lbs 7.7 oz
4.3 kg
Optional SC-N7 Speakers
Type 2 way 2 speakers Reex box
Drivers 12 cm cone bass-mid range x 1
2.5 cm balanced dome tweeter x 1
Frequency response 45 Hz - 40 kHz
Impedance 6 ohms
Dimensions (W x H x D) 5-45/64” x 9-11/64” x 9-19/64”
145 x 233 x 236 mm
Weight (kg/unit) 5 lbs 1.1 oz
2.3 kg
*Design and specications are subject to change without notice.
*"WMA"(Windows Media Audio) is a new audio codec developed by
Microsoft® in the United States of America.
*“Made for iPod,” and “Made for iPhone,” mean that an electronic
accessory has been designed to connect specically to iPod, or iPhone,
respectively, and has been certied by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this
device or its compliance with safety and regulatory standards.
*Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
*iPhone, iPod, iPod classic, iPod nano, iPod shue, and iPod touch are trademarks
of Apple Inc., registered in the U.S. and other countries.
Ports
In USB x 1
Ethernet x 1
WiFi antenna x 1
AUX in x 2
Digital optical x 1
Portable in x 1
Dock connector x 1
Out AUX out x 1
Subwoofer pre out x 1
Speaker output terminals
x 2
Headphones x 1
Other FM tuner antenna x 1
AM tuner antenna x 1

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
