81
S-102
JK701 00D 204 8719 005 19P HDMI CONNECTOR
JK702 00D 204 8746 007 3P PIN JACK(FG GBR)
JK801 00D 204 8711 003 1P/S-TERM(SYK22)
L201 00D 235 0166 003 INDUCTOR 100UH(7208M
L301 00D 235 0186 902 INDUCTOR 47UH(7B12N)
L302 00D 235 0185 903 INDUCTOR 47UH(7E10H)
L303 00D 235 0186 902 INDUCTOR 47UH(7B12N)
L401 00D 235 0183 905 INDUCTOR 2.2UH(7E06N
L702-704 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L803,804 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
S201 00D 279 0051 008 NTSA0WB203EE1B0
S202 00D 212 1204 000 SLIDE SW(SSAA110500)
ST101-103 nsp STYLE PIN
ST105,106 nsp STYLE PIN
T201 00D 231 8087 001 D/D TRANS(060478026)
W201,202 nsp M3 SCREW TERMINAL
X101 00D 399 0619 906 XTAL(27MHZ) +REF
X301 00D 399 0887 903 CSTCE16MOV53-R0 +2125
X401 00D 399 1113 906 X-TAL(L5030-16.660)
X501 00D 399 1116 903 X-TAL(S-24.576)
X701 00D 399 0864 900 XTAL(13.5MHZ) +REF
X901 00D 399 1009 007 X-TAL(S-4.332-14) for E2
Ref. No. Part No. Part Name Remarks Q'ty New
