S-52/S-52DAB/S-32
4.5. Execution of trace mode (error rate display) (See "Table 2 - Trace mode details")
Trace will be performed if the button is pushed after choosing operation.
(YY : selection mode [71 to 94], m : address [LBA][HEX], l : error rate [COUNT/SEC] [HEX])
Note) CD : Error rate of 75 frames is displayed (1 second).
The mode chosen when selection mode was changed into the trace execution and the button was pushed is performed
from the beginning.
When the button is pushed without changing selection mode, the mode under selection is performed from the beginning.
(If the button is pushed, the address corresponding to the chosen mode will be searched again.)
The pause mode is set after tracing is completed.
4.6. Other operations
① When the RETURN button is pressed, the mode returns to the previously selected mode.
(1) Test mode detailed table
Table 1: Servo adjustment value display mode details
Table 2: Trace mode details
Display
TYYmmmmmmllll
XXX
Name Size Meaning Remarks
T31 fbal0 16bits CD layer focus balance adjustment value FBAL range: 0x8000 < FBAL < 0x7FC0(Center:0x0000)
T32 tbal0 16bits CD layer tracking balance adjustment
value
TBAL range: 0x0000 < TBAL < 0x003F
T33 fcga0 16bits CD layer focus Loop Gain adjustment
value
1x for 0x100 [0x200 (2x) set to Typ.
(1x for 0x100, 2x for 0x200. Y/0x100 ratio calculation.)
Adjustment value 0x200 sets so that gain crossover reaches target.
T34 tkga0 16bits CD layer tracking Loop Gain adjustment
value
1x for 0x100 [0x200 (2x) set to Typ.
(1x for 0x100, 2x for 0x200. Y/0x100 ratio calculation.)
Adjustment value 0x202 sets so that gain crossover reaches target.
T39 Asoffs 16bits AS signal Offset value Upper 10 bit is valid
T40 Envoffse 16bits ENV signal Offset adjustment value Upper 10 bit is valid
T41 Foffse 16bits FE signal Offset adjustment value Upper 10 bit is valid
T42 Teoffse 16bits TE signal Offset adjustment value Upper 10 bit is valid
T43 RFfc 8bits RF signal frequency adjustment value
T44 RFbst 8bits RF signal Boost adjustment value
Adjustment range : 0x0000 〜 0x001F
0x0000 : 0dB
0x001F : 14dB
T45 RFgdl 8bits
RF signal low range group delay adjust-
ment value
T46 RFgdh 8bits
RF signal high range group delay adjust-
ment value
YY Contents Contents supplement
73 A display of CI error detection number of the inner circumference of
an address.
CD : C1 error detection number (x3)
77 A display of CI error detection number of the central circumference
of an address.
CD : C1 error detection number (x3)
81 A display of CI error detection number of the outer circumference of
an address.
CD : C1 error detection number (x3)
/
/
/
/
4.5. トレースモード ( エラーレート表示 ) の実行(表 2 トレースモード詳細参照)
動作を選択した後、 ボタンを押すとトレースを実行する。
(YY: 選択モード [71 〜 94]、m: アドレス [PBA][HEX]、l: エラーレート [CONT][DEC])
注 ): 表示するエラーレートは、75 フレーム (1 秒 ) 分の値。
トレース実行中に選択モードを変更し、 ボタンを押すと選択したモードを最初から実行する。
選択モードを変更せずに ボタンを押した場合も、選択中のモードを最初から実行する。
( ボタンを押すと、選択しているモードに対応したアドレスを再度サーチする。)
トレース終了時は、PAUSE 状態になります。
4.6. その他の動作
① RETURN ボタンを押すと、前の選択モードに戻る。
(1) テストモード詳細一覧表
表 1サーボ調整値表示モード詳細
表 2トレースモード詳細
表示
TYYmmmmmmllll
XXX 名称 サイズ 意味 備考
T31 fbal0 16 ビット CD 層フォーカスバランス調整値
FBAL の範囲は 0xB000<FBAL<0x7FC0。( センター :0x0000)
T32 tbal0 16 ビット CD 層トラッキングバランス調整値
TBALの範囲は 0x0000<TBAL<0x003F。
T33 fcga0 16 ビット CD 層フォーカス LoopGain 調整値 0x100 で 1 倍[0x200(2 倍 ) を Typ に設定する ]
(0x100 で 1 倍、0x200 で 2 倍。Y/0x100 の比率計算)
調整値 0x200 で Gain 交点が目標ターゲットになる様設定している。
T34 tkga0 16ビット
CD 層トラッキング LoopGain 調整値
0x100 で 1 倍[0x200(2 倍 ) を Typ に設定する。]
(0x100 で 1 倍、0x200 で 2 倍。Y/0x100 の比率計算)
調整値 0x202 で Gain 交点が目標ターゲットになる様設定している。
T39 Asoffs 16ビット AS 信号の Offset 値 上位 10bit が有効
T40 Envoffse 16 ビット ENV 信号の Offset 調整値 上位 10bit が有効
T41 Foffse 16 ビット FE 信号の Offset 調整値 上位 10bit が有効
T42 Teoffse 16 ビット TE 信号の Offset 調整値 上位 10bit が有効
T43 RFfc 8 ビット RF 信号の周波数調整値
T44 RFbst 8 ビット RF 信号の Boost 調整値 調整範囲: 0x0000 〜 0x001F
0x0000:0dB
0x001F:14dB
T45 RFgdl 8 ビット RF 信号の低域群遅延調整値
T46 RFgdh 8 ビット RF 信号の高域群遅延調整値
YY 内容 補足説明
73 内周の C1 誤り検出数とアドレスの表示 CD 時は C1 誤り検出数。(x3)
77 中周の C1 誤り検出数とアドレスの表示 CD 時は C1 誤り検出数。(x3)
81 外周の C1 誤り検出数とアドレスの表示 CD 時は C1 誤り検出数。(x3)
/
/
/
/
