Connect
For the method of connecting 5.1-channel speakers, see page 4.
For the method of connecting the TV, see page 5.
7.1-channel (Front Height Speaker) Connection
A power amplifier (sold separately) is required for this connection.
For 7.1-channel (Front height speaker) playback, set “Speaker Assign” in “Set Up Speakers”
(vpage 36) to “5.1CH + Front Height”.
FL FR
SW
FHRFHL
C
SL
SR
"69
*/
R
L
R
L
Power amplifier
•
•
n
•
•
7.1-channel/6.1-channel (Surround Back Speaker) Connection
A power amplifier (sold separately) is required for this connection.
For 7.1-channel (Surround back speaker) playback, set “Speaker Assign” in “Set Up Speakers”
(vpage 36) to “5.1CH + Surround Back”.
FL FR
SW
C
SL
SR
SBL SBR
"69
*/
R
L
R
L
Power amplifier
n
•
•
6.1-channel Connection
If using just one surround back
speaker (with a 6.1-channel
connection), connect to the “L”
side of the PREOUT connector.
n
