When connecting the speakers to an amplier, be sure to read the
amplier’s owner’s manual carefully and connect properly.
• Connect the input terminals on the rear panel of the speaker with
the speaker output terminals on the amplier, using the included
speaker cables.
• Connect the speaker for the left channel to the “L” terminal on the
amplier, the speaker for the right channel to the “R” terminal on
the amplier, making sure to check the polarities (“+” and “–”).
Ampliers have various speaker output terminals.
Check the owner’s manual of the amplier you are using for details.
NOTE
• Be sure to turn the amplier’s power off before connecting the
speakers to the amplier.
• If the polarities are inverted, the phase may be off and the sound
may have no bass component, making it seem unnatural. Be sure
to connect the polarities properly.
Connections
Connecting the speaker cables
Connect to amplier’s
“+”side: Striped core
Connect to amplier’s
“–” side: Plain core
“–” side
terminal: Black
“+” side
terminal: Red
Lever
1
Peel off the sheath from the tip of the
speaker cable, then rmly twist the
wires by hand so that they do not stick
out and cause short-circuits.
2
Press and lower the lever, and insert
the cable’s core wire into the hole.
3
Release the lever.
Gently pull on the speaker cable to
check that it is rmly connected.
Once connections are completed, pull gently on the speaker cables
to check that they are securely connected.
NOTE
Do not let the core wires of two speaker cables touch each other.
Doing so will short-circuit the amplier circuitry and damage the
amplier.
Type: 2-way · 2-speakers
Reex box
Frequency range: 50 Hz – 20 kHz
Input impedance: 6 Ω/ohms
Max. input: 60 W (IEC), 120 W (PEAK)
Sensitivity: 82 dB (1 W · 1 m)
Crossover frequency: 7 kHz
Speakers: 12 cm (4-3/4”) cone bass-mid x 1
2.5 cm (1”) balanced dome high
range x 1
Maximum external
dimensions: 145 (W) x 233 (H) x 236 (D) mm
(5-45/64” x 9-11/64” x 9-19/64”)
Weight: 2.3 kg (5 lbs 1.1 oz)
* For improvement purpose, specications and design are subject to
change without notice.
Specications
