Denon SYS-76HT Service Manual

10
SYS-76HT
DSW-76 Section
D103 00D DSW 7601 042 D 1N4148 197-031n4148-e
D105 00D DSW 7601 042 D 1N4148 197-031n4148-e
D106,107 00D DSW 7601 050 ZD 6.2V 199-15000625-e
D108 00D DSW 7601 042 D 1N4148 197-031n4148-e
D109 00D DSW 7601 051 ZD 16V 199-15001605-e
D110 00D DSW 7601 041 D KBL405/500V 197-00kbl405-e
D111,112 00D DSW 7601 055 D 1N5402 97-101n5402-e
D113,114 00D DSW 7601 042 D 1N4148 197-031n4148-e
D115 00D DSW 7601 041 D KBL405/500V 197-00kbl405-e
D117,118 00D DSW 7601 042 D 1N4148 197-031n4148-e
D130 00D DSW 7601 047 D 500mW/24V 199-05002403j-e
RESISTER GROUP
R121,122 00D DSW 7601 008 R 0.1ɹ/5W 113-500r1j10-e
R132 00D DSW 7601 006 R 1K/2W 110-20102jk2-e
R138 00D DSW 7601 009 SEMI VAR. R 3K/0.3W 114-03302m0-e
R167 00D DSW 7601 005 R TTC-802(JS)/NTC 109-1ttc802j0-e
CAPACITORS GROUP
C103 - ERECTRIC C 47U/25V 135-3476m25-e
C104 - CERAMIC C 100P/50V 130-sl101k503-e
C105 - ERECTRIC C 1U/50V 135-3105m50-e
C106 - CERAMIC C 0.047U/50V 130-3f473m503-e
C107 - FILM C 0.1U/50V 132-104j503-e
C108 - CERAMIC C 0.1U/50V 30-3f104z503-e
C109,110 - ERECTRIC C 100uF/16V 135-3107m16-e
C111 - ERECTRIC C 220U/16V 135-3227m16-e
C112 - ERECTRIC C 4.7U/50V 135-3475m50-e
C113 - CERAMIC C 0.1U/50V 30-3f104z503-e
C114 - ERECTRIC C 22U/50V 135-3226m50-e
C115 - CERAMIC C 0.1U/50V 30-3f104z503-e
C116 - CERAMIC C 1000P/50V 130-2b102k503-e
C117 - ERECTRIC C 100U/25V 135-3107m25-e
C118 - ERECTRIC C 22U/50V 135-3226m50-e
C119 - CERAMIC C 0.1U/50V 30-3f104z503-e
C120 - ERECTRIC C 100U/25V 135-3107m25-e
C121,122 00D DSW 7601 012 ERECTRIC C 4700uF/35V 135-4478m35-e
C123-128 - FILM C 0.022uF/100V 132-223ja03-e
C129,130 - ERECTRIC C 220U/10V 135-3227m10-e
C131,132 - FILM C 0.022uF/100V 132-223ja03-e
C133,134 00D DSW 7601 013 ERECTRIC C 4700uF/63V 135-4478m63-e
C135,136 - ERECTRIC C 100U/50V 135-3107m50-e
C137,138 - CERAMIC C 0.1U/50V 30-3f104z503-e
C139,140 - CERAMIC C 100P/50V 130-sl101k503-e
C141 - CERAMIC C 1000P/50V 130-2b102k503-e
OTHER PARTS DROUP
P101 - 7PIN CONNECTOR 175-1c07v01-e
P102 - 2PIN CONNECTOR 175-1d02v01-e
P103 - 5PIN CONNECTOR 175-1d05v01-e
P104 - 2PIN CONNECTOR 175-1c02v01-e
RY101 00D DSW 7601 054 RELAY/24V 71-udhss124d-e *
Ref. No nsp Part No. Part Name Remark Q'ty New

Denon SYS-76HT Specifications

General

Brand	Denon
Model	SYS-76HT
Category	Speaker System
Language	English
