SYS-76HT
DSW-76 Section
POWER P.W.B. UNIT ASS'Y
- TUBE 1M*10mm 156-h010010-e
- SHEET 361-NYL-00054-0LAE *
- TR BLACKET 361-FE-00051-0LAE *
- HEAT SINK 323-AL-00020-0LAE *
- M3*14 SCREW 351-AM03014A094-J
- M3*8 SCREW 352-AM03008D040-J *
Ref. No nsp Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
D301 00D DSW 7601 045 D 1/2W/12V 199-05001200j-e
RESISTER GROUP
R301 00D DSW 7601 007 R 0.56K/2W 110-20561jk3-e
CAPACITORS GROUP
C301 - FILM C 0.01uF/275V 132-103kb74-e
OTHER PARTS DROUP
P301 - 3PIN CONNECTOR 175-1d03v04-e
P302 - 5PIN CONNECTOR WIRE 162-5026d001-e *
P303 - 3PIN CONNECTOR 175-1d03v02-e
RY301 00DDSW 7601 056 RELAY 171-cs112lmr-e *
! 00D DSW 7601 015 SUB TRANS for E3 150-e0351201-e *
! 00D DSW 7601 014 SUB TRANS for E2 150-e0351200-e *
- TUBE 1M*10mm 156-h010010-e
Ref. No nsp Part No. Part Name Remark Q'ty New
