1. Mounting on the dry wall
1.1 To determine the screw hole position, please stick attached "wall mounted guide" in parallel to the
wooden wall where you need to hand the speaker.
Wall mounted Guide
Dry wall
1.2 Drill the holes on "wall mounted guide" "+" place with diameter of 8 mm by a powerful electric drill.
1.3 Stick EVA spacers seperately on the screw holes.
EVA
1.4 Use a hammer seperately nailing 2 plastic tubes into the holes.
