Denver TCS-86 - Product Controls Overview; Component Identification; Function Buttons

GB-2
B CONTROLS
11 13 14
8
9
12
11
15
10
1716
2
3
65
7
3
11 2
FUNCTION BUTTONS
1. POWER ON/OFF
2. FUNCTION
3. DBB
4. PRESET+/FOLDER+
5. PLAY/PAUSE
6. USB SOCKET
7. STOP
PLAY/PAUSE STOP SKIP-/TUNING- SKIP+/TUNING+ REPEAT PROG.
POWER ON/OFF FUNCTION DBB PRESET+/FOLDER+
USB
VOLUME
1 2 3 4
5 6 7 8 9 10 11 12 13 14
8. SKIP-/TUNING-
9. SD/MMC SOCKET
10. SKIP+/TUNING+
11. VOLUME-
12. REPEAT
13. VOLUME+
14. PROG.
1. RIGHT/LEFT COVER
2. SHOULD STRAP HOOK
3. BACK REVERBERANT TUBE
4. ANTENNA (Telescopic)
5. BACK COVER
6. CD FRONT COVER
7. CD OPEN
8. LCD
9. FUNCTION BUTTON
10. FRONT COVER
11. FRONT SPEAKER (RIGHT/LEFT)
12. CASSETTE COVER
13. CASSETTE BUTTON
14. CASSETTE COMPARTMENT
15. SPEAKER
16. AUX IN
17. AC IN
