11
2-3 Meters
Engine monitor
(1) Fuel level indicator
That indicates a fuel level in the fuel tank. Green lamps
will turn on with full tank. As the fuel level drops, the
numbers of the turn-on lamps decrease and at the sometime
the color of lamps changes from green to red.
Replenish the tank when there becomes only one lamp turned
on. The table below shows the relation between numbers of
turn-on lamps and fuel level.
Numbers of
lamps turned-on
Color of lamps Fuel level (L)
6 all green 55 to full
5 all green 45 to 54
4 all green 35 to 44
3 all green 27 to 34
2 all red 19 to 26
1 all red 0 to 18
(2) Hour meter
This meter indicates the total running time of the
engine.
