12
Temporal
artery
Dermis
Epidermis
Hypodermis
Heat transfer from TA to the Sensor Unit
Figure5
5. How does Temple Touch Pro™ work
Coretemperature isdenedas the temperatureof the blood
owinthepulmonaryartery.Underknownparametersonecan
ulizeTemporalArterybloodowcharacteriscstoderivethe
core temperature.
The SU is aached to the skin above the Temporal Artery
and measures heat ux and the skin temperature above the
TemporalArtery.TheMCUacquiresthedatafromtheSUand
accuratelycalculatesthepaent’scoretemperature.
13
6. Seng up Temple Touch Pro™
Note!
Setup of the TTP system shall follow the sequence below:
1. Make sure the VSM is turned on and fully operative
according to the instructions provided by the VSM
manufacturer.
2. ConnectthepowersupplytotheMCU’spowersupplyinlet.
(DisplayMCUallsegmentswillappear for 2 seconds).
3. Connect the MCU to the VSM.
4. RestarttheMCUbypressingandholdingtheRESETbutton
for3secondsinthefollowingcases:
• AfterplacingtheSUonthepatientforthefirsttime(Referto
section7:“InstructionforUse”).
• IftheSUwasseparatedfromthepatient’sskinatanypoint
aftertheinitialplacement.
• AfteranycomponentoftheTTPSystem(MCU/SCU/SU)was
disconnectedfromarunningTTPsetup.
• If any abnormal outcome is displayed on the Vital Signs
Monitor.
