INSTALLATION
Continued
6. Center cabinet mantel on hearth base
(see Figure 14, page 11). Make sure
mantelisushagainstwall.
7. Breakoffnailinganges(seeFigure16)
with hammer or pliers.
8. Place cardboard or other protective mate-
rial on top of hearth base. Carefully set
reboxonprotectivematerial,withback
ofreboxinsidemantelopening.
Figure 16 - Location of Nailing Flanges
Nailing
Flanges
Figure 17 - Inserting Firebox Into Cabinet
Mantel
BUILT-IN FIREBOX INSTALLATION
Built-in installation of this rebox involves
installingreboxintoaframed-inenclosure.
Thismakesthefrontofreboxushwithwall.
Optional perimeter trim is available (see Ac-
cessories, page 14) This perimeter trim will
extend past sides of rebox approximately
1/2". This will cover rough edges of the wall
opening.Ifinstallingamantelabovethere-
box, you must follow the clearances shown in
Figure 7, page 8. Follow the instructions below
toinstallthereboxinthismanner.
Figure 18 - Rough Opening for Installing
in Wall
39
3
/
8 "
27
7
/ 8 "
55
5
/ 8 "
34
3
/ 4 "
Figure 19 - Rough Opening for Installing
in Corner
34
3
/4"
17
3
/4"
33"
1. Frame in rough opening. Use dimensions
shown in Figure 18 for the rough opening.
If installing in a corner, use dimensions
shown in Figure 19 for the rough opening.
The height is 33", which is the same as
the wall opening in Figure 18.
2. Installgaspipingtoreboxlocation.This
installationincludesanapprovedexible
gas line (if allowed by local codes) after
theequipmentshutoffvalve.Theexible
gas line must be the last item installed on
the gas piping. See Connecting to Gas
Supply in log set owner’s manual.
3. Carefullysetreboxinfrontofroughopen-
ingwithbackofreboxinsidewallopening.
IMPORTANT: If installing perimeter trim,
see instructions included with perimeter
trim accessory. You must install shoulder
screws now.
4. If using blower accessory, install and
properly ground a GA3555 three-prong
120voltelectricaloutletinrebox.Follow
instructions included with kit.
5. Attach exible gas line to log set. See
Connecting to Gas Supply in log set
owner’s manual.
6. Carefully insert firebox into rough
opening.
7. Attach rebox to wall studs using nails
or wood screws through holes in nailing
ange(seeFigure20,page13).
