Desa HDFB32C User Manual

www.desatech.com
113900-01D 11
INSTALLATION
Continued
INSTALLING FIREPLACE SCREEN
1. Insert each rod through nine rings located
at top of screen (see Figure 13).
2. Insertrstrod into rearholein left side
ofrebox.Fastenrodtorearhole near
center of rebox using black shoulder
screw.
3. Insert other rod into front hole on right
sideofreboxandfastenusingremaining
shoulder screw.
Ring
Figure 13 - Installing Fireplace Screen
Rod
Front and
Rear Hole
Screen
Screw
FIREBOX INSTALLATION USING
OPTIONAL ACCESSORY MANTELS
Thisreboxmaybeinstalledusingthecabinet
mantel and hearth base accessories against
a wall in your home. Follow the instructions
belowtoinstallthereboxinthismanner.
Note: The instructions below show installation
using GMC11F/GMC12U/GMC13F series
cabinet mantels and the GC3333F/GC3334U/
GC3335F series hearth base accessories.
The hearth base accessory shown is optional
forthisinstallation.Youcaninstallreboxand
cabinetmanteldirectlyontheoor.
1. Assemble cabinet mantel, hearth base and
perimeter trim (Included with mantel). As-
sembly instructions are included with each
accessory.
2. If using a blower, install a properly grounded,
120 volt three-prong electrical outlet at
reboxlocationif anoutletisnot there.If
possible, locate outlet so cabinet mantel will
cover it when installed (see Figure 15).
Figure 14 - Placing Hearth Base
Accessory Against Wall
Electrical
Outlet
Hearth
Base
Gas Line
Access
Hole
Rigid Pipe and Gas
Shutoff Valve
3. Installgaspipingtoreboxlocation.This
installationincludesanapprovedexible
gas line (if allowed by local codes) and a
equipmentshutoffvalve.Theexiblegas
line must be the last item installed on the
gas piping. See Connecting to Gas Supply
in your log set owner’s manual.
WARNING: A qualified
service person must connect
rebox to gas supply. Follow all
local codes.
4. Place hearth base accessory against wall
at installation location. Cut an access hole
inhearthtoptorunexiblegaslinetore-
box (see Figure 14). Make sure to locate
access hole so cabinet mantel will cover
it when installed. Note: You can secure
basetooorusingwoodscrews.Coun-
tersink screw heads and putty over.
5. Route exible gas line through access
hole in hearth base.
Figure 15 - Installing Cabinet Mantel
Cabinet
Mantel
Electrical
Outlet
