PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
1a 121699-11 Front Log Right • • 1
1b 121699-10 Front Log Left • • 1
1c 121699-08 Middle Right Log • • 1
1d 121699-09 Middle Left Log • • 1
1e 121699-07 Bottom Log • • 1
1f 121699-12 Back Log • • 1
2 M11084-38 Screw • • 2
3 098304-01 Screw, #10 Phillips, Black • • 8
4 107486-01 ODS Pilot • 1
107485-01 ODS Pilot • 1
5 098249-01 Nut • • 2
6 112713-01 Pilot Bracket • • 1
7 112465-02 Front Burner Assembly • • 1
8 112466-02 Rear Burner Assembly • • 1
9 112705-03 Base Assembly • • 1
10 098271-10 Ignitor Cable • • 1
11 ** Firebox Bottom • • 1
12 098867-10 Gas Regulator • 1
098867-09 Gas Regulator • 1
13 101004-01 Front Burner Injector • 1
101004-04 Front Burner Injector • 1
14 102845-01 Inlet Tube • • 1
15 101382-01 Thermovalve Bracket • • 1
16 099387-09 Pilot Tube • • 1
17 112708-06 Burner Tube • • 1
18 097809-02 Adapter • • 1
19 099211-01 Screw • • 2
20 098544-01 Thermostat Clamp • • 1
21 101329-14 Thermostat Gas Valve Assembly • 1
101329-16 Thermostat Gas Valve Assembly • 1
22 101381-01 Cover and Piezo • • 1
23 101004-15 Rear Burner Injector • 1
101004-14 Rear Burner Injector • 1
24 101628-03 Flex Hose • • 1
25 901063-01 3/8" Flare x 1/2" NPT • • 1
26 M11084 Screw • • 4
27 121005-01 Air Shield • 1
100563-01 Warning Plate • • 1
101054-01 Lighting Instructions Plate • • 1
100565-01 Warning Plate Fastener • • 1
** Not a eld replacement part
