www.desatech.com
119303-01E
31
PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
1 101357-03 Top Outer Casing 1
2 ** Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-18 Louver Extruded 1
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 ** Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 101346-01 Outer Base 1
14 ** Firebox Wrapper 1
15 101614-02 Limit Switch (Thermal Disk) Assembly 1
16 M11084-26 Hex Screw, #10 57
17 098304-02 Phillips Pan Head Screw, #6-20 x 0.38" 4
18 101727-03 Screen Assembly 1
19 101398-03 Wire Harness 1
20 103650-01 Control Knob 1
21 119943-01 Blower Assembly 1
22 099123-01 Wire Clip 4
23 105649-01 Blower Speed Control 1
24 M11084-38 Hex Screw, #8-18 x 0.38" 4
25 101629-01 Plastic Bushing 2
26 098544-01 Clamp 1
27 102455-02 Extruded Louver 1
099038-01 Strain Relief Bushing 1
100639-01 Caution Decal 1
104313-01 Pin Hinge 1
104313-02 Pin Hinge 1
M10908-2 Screw, Slotted Hex Head Tapping 4
** Not a eld replaceable part.
