www.desatech.com
119303-01E
9
WARNING: These models have
-
-
currents move heat to wall sur-
smoke, aromatic candles, clean-
Note: Your replace is designed to be used in
zero clearance installations. Wall or framing ma-
terial can be placed directly against any exterior
surface on the rear, sides or top of your replace,
except where standoff spacers are integrally at-
tached. If standoff spacers are attached to your
replace, these spacers can be placed directly
against wall or framing materials.
Use the dimensions shown for rough openings
to create the easiest installation. See Built-In
Fireplace Installation, page 12.
IMPORTANT: Vent-free heaters add moisture
to the air. Although this is benecial, installing
replace in rooms without enough ventilation
air may cause mildew to form from too much
moisture. See Air for Combustion and Ventila-
tion, page 6.
IMPORTANT: Make sure the replace is level.
If replace is not level, log set will not work
properly.
Use the correct gas type (natural or propane/
LP) for your replace. If your gas supply is not
correct, do not install replace. Call dealer
where you bought replace for proper type
replace.
-
This replace has a blower assembly with an
electrical cord. The electrical cord is ve feet
in length. You must locate replace within
reach of 120-volt grounded electrical outlet. If
not, you must install an electrical outlet within
reach of replace power cord. The GA3555
outlet accessory may be used for built-in
installation when a blower is installed.
INSTALLING HOOD
Install hood to rail already installed in replace
as shown in Figure 5. Use 3 Phillips screws
provided.
INSTALLATION
Continued
Figure 5 - Installing Hood
Screw
Hood
Rail
ASSEMBLING AND ATTACHING
IMPORTANT: If you are recessing the rebox
in a wall, do not attach trim at this time. See
Built-In Fireplace Installation, page 12.
Note: These instructions are for assembling
and attaching trim to replace.
1. Remove packaging from three pieces
of trim.
2. Locate four screws, two adjusting plates
with set screws, and two shims in the
hardware packet.
3. Align shim under adjusting plate as shown
in Figure 6, page 10.
4. Slide one end of adjusting plate/shim
in slot on mitered edge of top trim (see
Figure 6, page 10).
To Next Page
