6159932570_09
10 / 104 04/2014
OFFSET OPEN - IN-LINE
Model Part number
Torque (Nm) Torque (ft.lb) Speed Weight
Nom Min Max Nom Min Max rpm kg lb.
EID20-900-OE12-L31-H14-W38 6151658350 22 6 28 16.2 4.4 20.6 840 1.9 4.2
EID32-800-OE14-L34-H18-W40 6151658360 40 8 44 29.5 5.9 32.5 790 1.9 4.2
Model Part number
L Ø A Ø B Ø C
mm in. mm in. mm in. mm in.
EID20-900-OE12-L31-H14-W38 6151658350 550 21.6 46 1.81 37 1.46 40 1.57
EID32-800-OE14-L34-H18-W40 6151658360 580 22.8 46 1.81 37 1.46 40 1.57
Model Part number
A B C A/F
mm in. mm in. mm in. mm in.
EID20-900-OE12-L31-H14-W38 6151658350 14 0.55 38 1.49 8.0 0.31 12 0.47
EID32-800-OE14-L34-H18-W40 6151658360 18 0.71 40 1.57 10.4 0.41 14 0.55
L
Ø44
Ø45.7
ØA
ØB
ØC
A
B
C
A/F
