Desoutter EAD - Page 31

6159932570_09
31 / 10404/2014
Kit adapter
EAD 20-1300 EAD 32-900 EAD 50-900 EAD 50-900-HAD EAD 70-700-HAD EAD 70-800 EAD 70-800 Sq.1/2 EAD 80-650 EAD 105-500 EAD 105-500-HAD EID 25-1200 EID 32-900 EID 44-1200 EID 65-900 EID 75-800 High Medium Low
Item Description Part no. Qty Qty Wear
L Kit adapter 6153985050 1 1 1 1 1 1 X
Nut adapter - 1 1 1 1 1 1
Adaptation 6155840600 1 1 1 1 1 1
Screw FX90 M4X10 - 8 8 8 8 8 8
Spacer - 8 8 8 8 8 8
Screw HC M3X5 conical
pointed
- 2 2 2 2 2 2
L Kit adapter 6153985290 1 1 1 X
Nut adapter - 1 1 1
Adaptation 6155840580 1 1 1
Screw FX90 M4X10 - 8 8 8
Spacer - 8 8 8
Screw HC M3X5 conical
pointed
- 2 2 2
EAD 20-1300 EAD 32-900 EAD 50-900 EAD 50-900-HAD EAD 70-700-HAD EAD 70-800 EAD 70-800 Sq.1/2 EAD 80-650 EAD 105-500 EAD 105-500-HAD EID 25-1200 EID 32-900 EID 44-1200 EID 65-900 EID 75-800
High Medium Low
K5 Service parts kit SHE4 6153985240 1 1 1 X
O-Ring - 1 1 1
Needle bearing - 1 1 1
Circlip Internal - 1 1 1
Spacer - 1 1 1
Circlip for Shaft - 1 1 1
L
