DesQ 8000 - Product Diagram

Product Diagram
1 2 3 4 5 6
7
8
11
12
132
14
15
16
17
10
9
1. STOP Button
2. DRY/WET Button
3. NORMAL VAC Button
4. SOFT VAC Button
5. SEAL ONLY Button
6. OUTSIDE VAC Button
7. Upper Sealing Bar
8. Upper Sealing Sponge
9. Bag Roll Holder (width adjustable)
10. Cutting knife
11. Lower Sealing Sponge
12. Lower Sealing Bar
13. Lid
14. Control Panel
15. Air Intake
16. Vacuum Chamber (detachable)
17. Lid Unlockers (two sides)
18. Exterior Hose Port/
“MANUAL VAC Port”
18
6
