Dettson CMO32-II - Figure 4: Parts List, Model 50; Table 4: Parts List, Model 50

12
Figure 4 : Parts List, Model 50
Table 4 : Parts List, Model 50
ITEM PART # DESCRIPTION COMMENTS
1 B10373-05 TANK, REPLACEMENT
2 G14G007 GASKET, 3-3/4"OD 1" ID LDPE WHITE
3 G11F002 TEMPERATURE/PRESSURE VALVE 150 PSI 3/4"
4 G99Z019 OVERFLOW TUBE, 3/4"NPT x 42"
5 B10322 WELL.
6 B10365-04 FRONT PANEL ASSEMBLY
7 R02G003 DOUBLE AQUASTAT
8 B00403 OBSERVATION DOOR
9 B10083 INSERTION COLLAR
10 B10291 FLOOR ASSEMBLY
11 B00619-53 INSULATION
12 B10074 COLLAR, FRONT INTERIOR
13 B10306 COLLAR INSULATION, FRONT INTERIOR
14 B10368 HEAT CHAMBER AND INSULATION ASSEMBLY (includes items 0, 11, 12, 13, 14 & 15)
15 B10093 REFRACTORY HEAT CHAMBER
16 B10424 CASING INSULATION
17 B10366 CASING ASSEMBLY, RIGHT SIDE
18 G99Z003 MAGNESIUM ANODE 3/4"NPT .750" x 30"
19 G99Z022 DIP TUBE 3/4"NPT x 29"
20 Z06G001 BLOCKED VENT SHUT-OFF BVSO-225
21 G99Z004 NIPPLE WITH PLACTIC SLEEVE 3/4" x 4" ZINC
22 G14F006 FLUSH PLUG 2" BLACK PLASTIC
23 G14G001 GASKET, 2-7/8" OD 1" ID LDPE WHITE
24 B10369-01 TOP PANEL ASSEMBLY
25 B10299 INSULATION, TOP PANEL
26 B03114-02 ELECTRICAL KIT BVSO
27 B10294 CASING, LEFT SIDE
28 G11Z025 DRAIN VALVE, 3/4" x 3"
B50025 rev. E
B50025 rev. F
