PARTS LIST
Model : HGRC (HGRC068 to HGRC340)
29
ITEM DESCRIPTION NUMBER COMMENTS
1A Heat exchanger B01234-0X HGRC heating
1B Heat exchanger B01235-0X HGRC hot water
2A Intermediary heat exchanger header (Steel) K01001 Without inlet/outlet connector
2B Intermediary heat exchanger header (Stainless steel) K01002 Without inlet/outlet connector
3A Heat exchanger header (Steel) K01003 HGRC heating
3B Heat exchanger header (Stainless steel) K01004 HGRC hot water
4 Finned tube kit K01005-0X With supporting plates
5 Heat exchanger header mounting kit K01006 Includes nuts, bolts and silicone joint (12)
6 Heat exchanger deflector B00263-0X
7A Burner drawer kit K01014-0X Without modulating valve - Constant
7B Burner drawer kit K01015-0X Without modulating valve - Hot surface ignition
7C Burner drawer kit K01016-0X With modulating valve - Hot surface ignition
7D Burner drawer kit K01019-0X Without modulating valve - Electronic (Used with No. 42)
7E Burner drawer kit K01020-0X With modulating valve - Electronic (Used with No. 42)
8 Draft hood assembly K01017-0X
9 Complete combustion chamber K01007-0X Includes all panels and insulation staples
10 Outside heat exchanger insulation B01318-01
11 Inside heat exchanger insulation B01318-03
12 Front / rear inside heat exchanger insulation B01318-1X
13 Front / rear outside heat exchanger insulation B01318-2X
14 Top outside heat exchanger insulation B01318-02
15 Top inside heat exchanger insulation B01318-04
16 Top heat exchanger insulation B01318-3X
17 Rear outside panel B01352-0X
18 Right heat exchanger panel B01316
19 Exterior front panel B01351-0X
20 Header cover panel, side B01370-01
21 Header cover panel, side B01370-02
22 Header cover panel, bottom B01369
23 Header cover panel, top B01331 With inlet/outlet openings
24 Header cover panel, top B01330 Without inlet/outlet openings
25 Heat exchanger support kit K01008-0X Includes all tracks and supports
26 Floor B01317-0X
27 Heat exchanger adaptor B01323-0X
28 Heat exchanger support, interior B01320-02
29 Special screw kit A00259
30 Side panel electrical box B01356-02 Fuse side
31 Side panel electrical box B01356-01 Power side
32 Electrical box B01354
33 Cover, electrical box K01010 With logo label
34A Fuse, 1A L01G001 Constant pilot only
34B Fuse, 3A time-delay L01G008 Electronic pilot only
35 Fuse holder L02G001
36 8 position terminal strip K01011 Includes 2 terminal strips and 2 retaining staples
37 Ground connector kit K01012
38 6 position terminal strip L05F002
39 Relay 24VAC SPDT L01H009 Circulator relay
40A Transformer 120V / 24V 20 VA L01F002 Constant pilot only
40B Transformer 120V / 24V 40 VA L01F003 Electronic pilot only
41 Simple aquastat R02F001
42 Ignition control R03I005
HGRC-238 to HGRC-340 (not used anymore)
43 Rear burner support B01337-0X
44 Right drawer side B01339-1X
45 Left drawer side B01339-0X
46 Burner deflector B01346-0X
47 Front deflector B01455-0X
48 Drawer cover B01340-0X
49 Drawer collector B01373-0X Without valves and accessories
