PARTS LIST
Model : HGRC (HGRC068 to HGRC340)
30
MODEL
X
HGRC068 1
HGRC105 2
HGRC136 3
HGRC170 4
HGRC204 5
HGRC238 6
HGRC272 7
HGRC306 8
HGRC340 9
TABLE OF VARIABLES
When the part number changes based on the
size of the furnace, complete the code in the
“NUMBER” column by replacing the X with the
corresponding number in the table to the right.
ITEM DESCRIPTION NUMBER COMMENTS
50A Ignition cable R03Z004 Electronic pilot HGRC-238 to HGRC-340
50B Thermocouple 30" R02K004 Constant pilot
50C Wire harness B01460 Electronic pilot HGRC-068 to HGRC-204
51A Constant pilot R03G004
51B Electronic pilot R03H004 Elect.pilot HGRC-068 to HGRC-340
51C Electronic pilot R03H002
HGRC-238 to HGRC-340 when #42 is used
52A Gas valve 1/2” X 1/2” R01F020 Constant pilot, HGRC-068 to HGRC-204
52B Gas valve 3/4” X 3/4” R01F021 Constant pilot, HGRC-238 to HGRC-340
52C Gas valve 1/2” X 1/2” R01J004 Elect. pilot HGRC-068 to HGRC-204
52D Gas valve 3/4” X 3/4” R01H009
HGRC-238 to HGRC-340 when #42 is used
52E Vanne à gaz 3/4” X 3/4” R01J007 Elect. pilot HGRC-238 to HGRC-340
53A Gas supply pilot tube K01013-01 Includes 2 parts HGRC-068 to HGRC-136
53B Gas supply pilot tube K01013-02 Includes 2 parts HGRC-170 to HGRC-238
53C Gas supply pilot tube K01013-03 Includes 2 parts HGRC-272 to HGRC-340
54A Modulate gas valve 1/2” X 1/2” R01K001 HGRC-068 to HGRC-204
54B Modulate gas valve 3/4” X 3/4” R01K004 HGRC-238 to HGRC-340
55 Hgrc burner B01393 Each
56A Low altitude natural gas orifice HGRC (Dim 0.111) B01238-01 HGRC low altitude only (each)
56B High altitude natural gas orifice HGRC (Dim 0.104) B01238-03 HGRC high altitude only (each)
56C Low altitude propane gas orifice HGRC (Dim 0.064) B01238-02 HGRC low altitude only (each)
56D High altitude propane gas orifice HGRC (Dim 0.055) B01238-04 HGRC high altitude only (each)
57A Thermo-pressure gauge 0/60 psi R02L001 HGRC only
57B Thermo-pressure gauge 0/250 psi R02L003 Hot water HGRC only
58A Reducer hexagonal 1” X 1/4” steel G08F003 Heating HGRC only
58B Reducer hexagonal 1” X 1/4” stainless steel G08G001 Hot water HGRC only
59A T reducer 1 1/4 x 1 1/4 X 1 steel G05H004 Heating HGRC only
59B T reducter 1 1/4 x 1 1/4 X 1 brass G05I001 Hot water HGRC only
60 Drain valve G11Z001-1
61A Steel nipple 3/4" X 2" G01J002 Heating HGRC only
61B Steel nipple 3/4" X 2" G02J006 Hot water HGRC only
62A Steel nipple 1 1/4" X 5" G01L007 Heating HGRC only
62B Stainless steel nipple 1 1/4" X 5" G02L003 Hot water HGRC only
63A Safety valve #30 G11F012 Heating HGRC only
63B Safety valve temp/pressure 150# G11F020 Hot water HGRC only
64 Complete propane conversion kit K01018 Includes conversion kit with orifices
65 Propane conversion kit R01Z003
66 Normal altitude propane HGRC orifices B01238-02
67 Orifice insert .012 R04G003
68 Draft hood spill out switch R02N007
69 Burner roll out switch R02N007
70 Therm-o-disk protector B01396
71 Therm-o-disk holder B01338
