Devair PROdry - Parts List and Identification; Separator and Strainer Parts; Electrical Components List; Condenser Fan and Refrigeration Parts

Maintenance Kits
For Dryer Models Kit Number
20, 25, 35 4KMTIH
50 HITMK6
75 HITMK5
13
PARTS LIST
PARTS DESCRIPTION 20 25 35 50 75
Separator
*Separator/Filter Cartridge E9-16 E9-16 E9-16 E9-20 E9-24
42-9S02-9S61-9S61-9S61-9SeveelS retliF
80-0714.5080-0714.5080-0714.5080-0714.5080-0714.50msinahceM niarD*
60-0180.3050-0180.3040-0180.3040-0180.3040-0180.30lwoB
61.255.023961.255.023941.255.023941.255.023941.255.0239lwoB gnir-O*
Inlet (Compressed Air) Strainer
2.537.13742.537.13741.537.13741.537.13741.537.1374telni ,reniartS
7.537.13747.537.13745.537.13745.537.13745.537.1374reniarts ,neercS*
Electrical
7.607.01167.607.01167.607.01167.607.01167.607.0116ffo/no hctiwS
Light, Fault (amber)
115/1/60
6350.451.10 6350.451.10 6350.451.10 6350.451.10 6350.451.10
Light, Fault (amber)
220-240/1/50
6350.451.11 6350.451.11 6350.451.11 6350.451.11 6350.451.11
Cord Set
115/1/60
03.7133-10 03.7133-10 03.7133-10 03.7133-11 03.7133-11
Cord Set
230/1/60
03.7133-24 03.7133-24 03.7133-24 03.7133-25 03.7133-25
Cord Set
220-240/1/50
03.7133-12 03.7133-12 03.7133-12 03.7133-12 03.7133-12
Capacitor, run
115/1/60
5910.103.17 5910.103.17 5910.103.17 5910.103.13 5910.103.13
Capacitor, run
220-240/1/50
5910.103.18 5910.103.18 5910.103.18 5910.103.49 5910.103.50
Capacitor, run
208-230/1/60
5910.103.18 5910.103.18 5910.103.18 5910.103.49 5910.103.49
Overload, Compressor
115/1/60
5925.571.12 5925.571.12 5925.571.12 5925.571.15 5925.571.15
Overload, Compressor
208-230/1/60
5925.571.13 5925.571.13 5925.571.13 5925.571.16 5925.571.16
Overload, Compressor
220-240/1/50
5925.571.14 5925.571.14 5925.571.14 5925.571.14 5925.571.14
Switch, fault light w/conn. 03.7419-02 03.7419-02 03.7419-02 03.7419-03 03.7419-03
Condenser Fan
Fan Motor
115/1/60
6105.226.2 6105.226.2 6105.226.2 6105.226.7 6105.226.7
Fan Motor
220-240/1/50
6105.226.4 6105.226.4 6105.226.4 6105.226.9 6105.226.9
Fan Motor
208-230/1/60
6105.226.4 6105.226.4 6105.226.4 6105.226.9 6105.226.9
Fan Blade
115-1-60
6105.378.2 6105.378.2 6105.378.2 6105.378.4 6105.378.4
Fan Blade 208-240-1-50/60 --- --- --- 6105.378.6 6105.378.6
Refrigeration System
Compressor 115/1/60 4130.106.67 4130.106.67 4130.106.67 4130.106.70 4130.106.70
Compressor 208-230/1/60 4130.106.68 4130.106.68 4130.106.68 4130.106.71 4130.106.71
Compressor 220-240/1/50 4130.106.69 4130.106.69 4130.106.69 4130.106.72 4130.106.72
51.211.031451.211.031431.211.031431.211.031431.211.0314resnednoC
Hot gas by-pass valve 4130.690.21 4130.690.21 4130.690.21 4130.690.22 4130.690.22
21.561.031421.561.031421.561.031421.561.031421.561.0314reyrD/retliF
Fan Pressure Switch 4130.139.21 4130.139.21 4130.139.21 4130.139.21 4130.139.21
Cabinet
4.332.06444.332.06443.332.06443.332.06443.332.0644riA tneibmA ,retliF*
Grommet (light & switch, front panel) 9320.302.11 9320.302.11 9320.302.11 9320.302.11 9320.302.11
2.032.03392.032.03392.032.03392.032.03392.032.0339gnitnuom ,tooF
* Maintenance kits for the above models are available "*" indicates items included in the kits.
