DEVI Devireg 530 Series - Connection Diagrams for Devireg 530, 531, and 532

8
15 A
Max.Load
NC NC NC
5-35°C
N
L
LOAD
LOAD
N
L
N L
15 A
Max.Load
NC
N L
C T N
5-35°C
20-50°C
N
NTC
L
LOAD
LOAD
N
L
15 A
Max.Load
NC
N L
5-45°C
N
NTC
L
LOAD
LOAD
N
L
C T N
Devireg™ 530
Type D530
Configuration - Max. floor temp.
Devireg™ 531
Type D531
Devireg™ 532
Type D532
Temperature
limiter
NC =
no connection
NC =
no connection
