Reassemble the thermostat by fi rst placing the
frame, then mount the display module and
fi nally press the front cover into place.
Note:
The display must be gently remounted on the
base module, ensuring that the 8-pin plug is
placed accurately by using the four tabs sur-
rounding it.
When remounting the two screws in the side,
please DO NOT over tighten them.
They just need to be barely fastened.
11
