DeVilbiss ADVANCE HD Series - Kit Contents; Construction Features; Materials of Construction; Specifications & Technical Data

4 © 2012 Finishing Brands UK Ltd.
Kit contents (all models)
1
ADVANCE HD Suction or Pressure Feed Spraygun
1
Spanner (10mm and 14mm A/F)
1
KR 1 litre Suction feed Cup (Suction models only)
1
Torx/Flat blade screwdriver
1
Cup Filter (Suction models only)
1
Cleaning Brush
1
Set of 4 coloured identification rings
1
Service bulletin
Construction Features
1
Air Cap (nickel plated brass for long durability)
10
Fan Air Adjustment (stepless regulation for fan
to round spray)
2
Air Cap Retaining Ring (allows easy rotation of air
cap)
11
Fluid Adjustment (stepless regulation of fluid
volume)
3
Fluid Nozzle (ideal for automotive topcoat systems)
12
Interchangeable Colour ID System (4 coloured
rings supplied)
4
Fluid Needle (grooved stem for easy removal)
13
Anodised, forged aluminium gun body
(ergonomic, good looking & durable, easy to
clean)
5
Fluid Inlet (3/8 BSP thread – accepts DeVilbiss and
most other cup systems)
14
1 litre Aluminium Suction Cup (Suction models
only)
6
Air Inlet (universal thread, accepts ¼ BSP & 1/4
NPS)
15
Cup Lid with Drip Free diaphragm
7
Self Adjusting Needle Packing (for trouble free
operation)
16
Air Valve (design offers low pull force & low
pressure drop)
8
Trigger (ergonomic for comfort)
17
Gun acceptable for waterborne and solvent
borne applications
9
Trigger Stud & Screw (easy replacement design)
Materials of Construction
Gun Body
Anodised aluminium
Air Cap,
Nickel plated brass
Fluid Nozzle, Fluid Needle, Fluid Inlet, Trigger Stud
Stainless steel
Adjusting Knobs
Anodised aluminium
Springs, Clips, Screws
Stainless steel
Seals, Gaskets
Solvent resistant materials
Trigger
Chrome plated steel
Air Inlet, Body Bushing, Spreader Valve Body, Air Valve Nut,
Air Cap Retaining Ring, Knobs
Chrome plated brass
Air Valve Assembly
Stainless Steel, HPDE
Cup
Aluminium Cup, Lid, Tube and Cam
Specifications & Technical Data
Air Supply Connection
Universal 1/4" (fits ¼” BSP and 1/4" NPS male)
Maximum Static Air Inlet Pressure
P1 = 12 bar (175 psi)
Maximum Static Fluid Inlet Pressure
P2 = 14 bar (203 psi)
Fluid Supply Connection
Universal 3/8" (fits 3/8” BSP and 3/8” NPS male)
Service Temperature
0 to 40°C (32 to 104°F)
Gun Weight (gun only)
(cup only)
495g
420g
