EN
Soak cap or tip in suitable solvent
and thoroughly clean.
Replace fluid tip or air cap if
necesarry.
If the defect is not inverted, it is on the fluid tip. Clean tip. If problem persists, renew tip.
CAUSE
Replace fluid tip or air cap if
necesarry.
Determine if the obstruction is on the air cap or the fluid tip. Do this by making a test spray pattern. Then, rotate
the cap one-half turn and spray another pattern. If the defect is inverted, obstruction is on the air cap. Clean the
air cap as previously instructed. Also check for dried paint just inside the cap centre hole opening, remove by
washing with solvent.
Replace fluid tip or air cap if
necesarry.
Remedies for the top-heavy, bottom-heavy, right-heavy and left-heavy patterns.
Soak cap or tip in suitable solvent
and thoroughly clean.
Dirt or damage on left or right side
of fluid tip exterior.
CORRECTION
