SB-2-252-P (12/2017) 3 / 8
EN
www.carlisleft.com
AC D E EE EX FF FX FW GX
Tip
Orifice
in./ .110 .080 .070 .070 .070 .055 .042 .063 .034
mm
2.8 2.2 1.8 1.8 1.8 1.4 1.1 1.6 .9
24 P P P
30 P S S S S
58 S P P P
62HD P
64HD P
67HD P
69HD P
80 S S S S
704 P P P
765 P P P
777 P P
797 P P
9000 S S S S
P = Pressure Feed Combination
S = Suction Feed Combinations
NOZZLE COMBINATIONS
Air Cap
Sizes
Order
From
Chart 2
Fluid Tip and Needle Size
Order From Chart 3
CHART 1
CHART 3
No. on Ref. No. (1) Ref. No. (3)
Cap Air Cap Air Cap Less Ring*
Order With Ring
24 AV-40-24
30 MB-4039-30
58 AV-439-58
62HD MB-4039-62HD
64HD MB-4039-64HD
67HD MB-4039-67HD
69HD MB-4039-69HD
80 MB-4039-80
704 AV-1239-704
765 AV-1239-765
777 31767-777
797 AV-1239-797
9000 AV-440-9000
AIR CAPS
CHART 2
➞
*MBC-368 Retaining Ring
(sold separately) is required
to mount Air Cap to Gun.
FLUID TIPS AND NEEDLES
Tip Orifice Size
In. / (mm)
Ref. No. 4
Fluid Tip
Ref. No. 33
Fluid Needle
303 GR. S.S. TIPS AND 303 GR. S.S. NEEDLES
.110 (2.8) AV-2115-AC JGA-402-C
.086 (2.2) AV-2115-D JGA-402-DEX
.070 (1.8) AV-2115-E JGA-402-E
.070 (1.8) AV-2115-EX JGA-402-DEX
.055 (1.4) AV-2115-FF JGA-402-FF
.042 (1.1) AV-2115-FX JGA-402-FX
.063 (1.6) AV-2115-FW JGA-402-FF
.034 (.9) AV-2115-GX - - -
OPTIONAL 300 GR. S.S. W/ U.H.M.W.
POLYETHYLENE NEEDLE SEAT
.086 (2.2) AV-4915-D - - -
.070 (1.8) AV-4915-E - - -
.055 (1.4) AV-4915-FF - - -
.042 (1.1) AV-4915-FX - - -
.028 (.8) AV-4915-G - - -
OPTIONAL CARBOLOY TIPS AND NEEDLES
.086 (2.2) AV-1415-D JGA-409-D
.070 (1.8) AV-1415-EE JGA-409-DEEE
.055 (1.4) AV-1415-FF JGA-409-FF
