SB-2-252-P (12/2017) 5 / 8
EN
www.carlisleft.com
*Apply QH-130 (Loctite #242 med. strength blue) sealing
compound on threads.
30
31
29
28
7
8
9
19
18
34
22
Fluid Inlet
Nipple
3/8 NPS (M)
Torque to
20-25 ft. lbs.
32
33
11
25
26
27
6
5
1
2
4
3
Torque to
12-15 ft. lbs.
10
21
*23
11
16
15
14
13
12
17
Air Inlet
Nipple
1/4 NPS (M)
* 24
Torque to
15 ft. lbs.
20
*
Δ
Δ
Detail Ref. No. 18 - Two piece packing covered by
U.S. Patent No. 5,209,501.
+ Tapered edge faces out towards packing nut.
+Inner PTFE Piece
Fluid Packing
Nut
Fluid Needle
Outer
U.H.M.W.
Poly. Piece
See GTI-33 Baffle Seal Replacement
Instructions on Page 4.
