Technical specifications
Features:
- compact mixer for small PA, recording and broadcasting purposes
- 2 (MX-4) or 4 (MX-6) mono inputs (MIC/Line)
- Insert option for all mono channels
- Common +48V phantom power for all microphone inputs
- Gain control for each input
- 3-band EQ for each input
- L/R PAN sound balancing function for each input
- AUX level control for each input
- FX level control for each input
- PEAK limiter LED for each input
- Stereo input channel
- Built-in USB MP3-player
- Built-in echo effect processor with adjustable level and duration
- Main Mix fader
- Mono AUX output, for monitoring applications (use AUX levels to make a monitor mix)
- Mono FX send, to use an external effects processor
- Headphone output with adjustable volume
- Master LED VU meters with CLIP indicators
- Tape out for recording applications (mixed output)
Microphone inputs:
- Type connector: XLR
- Frequency response: 10 Hz to 60 kHz
- Gain range: 12 to +60 dB
- Maximum input level: +15 dBu
- Signal/noise ratio: -90dB, A-weighted
- Impedance: Approximately 4.8 kOhm
Line inputs:
- Type connector: 6.35 mm jackplug TRS, electronically balanced
- Impedance: 20 kOhm balanced, 10 kOhm unbalanced
- Gain range: -10 to +40 dB
- Maximum input level: +22 dBu
EQ
- High: 12 kHz +/- 15 dB
- Mid: 2.5 kHz +/- 15 dB
- Low: 60 Hz +/- 15 dB
Stereo inputs:
- Type connector: 6.35 mm jackplug TRS, electronically balanced
- Impedance: 20 kOhm balanced, 10 kOhm unbalanced
- Maximum input level: +22 dBu
Main output:
- Type connector: 6.35 mm jackplug TRS, electronically balanced
- Maximum output level: +18 dBu
Tape output:
- Type connector: Stereo RCA, unbalanced
- Impedance: Approximately 1 kOhm
- Maximum output level: +18 dBu
Headphones output:
- Type connector: 6.35 mm jackplug TRS
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 27-08-2013 RV Revision date + author initials: 20-02-2014 RV
