Specifications
General specifications for all models:
– lightweight speaker cabinet with plastic housing
– 10, 12 or 15 inch active speaker with woofer and compression driver + horn
– metal grille
– acoustic foam behind grille to prevent any unwanted matter from getting inside the speaker
– grille covers the front of the speaker for optimal protection
– tweeter has special horn construction for optimal sound dispersion
– high-quality plastic housing with black lacquer
– rubber feet
– built-in mini mixer that includes AUX input, (stereo) line inputs, tone and volume controls
– cabinet design also suitable for use as a floor monitor
– 35 mm stand flange with tightening knob secure mounting on a speaker stand and optimal dispersion of
the high tones
– built-in clip limiter
– Power LED indicator and Clip LED indicator
– 2-band tone control (Bass / Treble)
– IEC C14 power input with fuse holder
– on/off switch
Mixer connectors:
– mini TRS jack line input
– 3-pin XLR or jack plug balanced input, switchable between line and mic signal
– 3-pin XLR or stereo RCA input (mono summing) line input
– 3-pin XLR line output (master line out)
Technical specifications per model:
Model Onyx 10A Onyx 12A Onyx 15A
Frequency range 58 Hz – 19 kHz 53 Hz – 19 kHz 46 Hz – 19 kHz
Amplifier power (RMS /
Peak)
220 W / 880 W 300 W / 1200 W 350 W / 1400 W
Amplifier type Class D + Class AB
maximum SPL 132 dB 134 dB 136 dB
Low tone speaker 10-inch woofer with 2-
inch voice coil
12-inch woofer with 2.36-
inch voice coil
15-inch woofer with 3-
inch voice coil
High tone speaker 1.35-inch compression driver with 1-inch throat exit
high tone driver with horn
dispersion
90 x 60 degrees (H x V), asymmetrical
Crossover frequency 3.2 kHz 2.8 kHz 2.6 kHz
Connection voltage 110 / 230 V AC, 50/60 Hz
Fuse T2.0 AL 250V
Nominal maximum power
consumption
390 W
Dimensions 357 x 593 x 365 mm 413 x 677 x 410 mm 480 x 762 x 437 mm
Weight per speaker 11.5 kg 14.7 kg 20 kg
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials 23-09--2017 RV Revision date and author's initials: -
