3.3 Functions
The dLAN 500 duo+ has a monitoring light (LED), two
network jacks and an encryption button.
Monitoring light
The monitoring light (LED) shows all of the statuses for
the dLAN 500 duo+ by illuminating and/or flashing in
different ways:
쎲 The LED flashes at uniform intervals (of 2 s) if
the dLAN 500 duo+ is connected to the mains
supply but there is no dLAN connection.
쎲 The LED lights up if the dLAN 500 duo+ is
ready to operate and there is a dLAN connec-
tion.
쎲 The LED flashes quickly if the encryption process
(pairing) is being performed in the dLAN net-
work.
쎲 The LED flashes at irregular intervals (1 s/
15 s) if the dLAN 500 duo+ is in PowerSave
mode.
Network connections
These are the connection points on the
dLAN 500 duo+ for connecting it to a computer and/or
another network device with the network cable (includ-
ed).
Encryption button
Data encryption at the touch of a button; For more in-
formation on the functions of the encryption button,
please see the chapter 4.2 dLAN network encrypti-
on at the touch of a button.
Integrated electrical socket
If you connect additional network devices using a mul-
tiple socket, plug this multiple socket into the electrical
socket of the dLAN 500 duo+. The integrated mains
filter eliminates any noise of connected devices and si-
gnificantly improves data transmission in the home
network.
