Devolo dLAN 500 WiFi User Manual

dLAN network 33
devolo dLAN 500 WiFi
5.2 dLAN Cockpit App
dLAN Cockpit App is an app for monitoring and en-
cryption, which you can use to search out all other ac-
cessible dLAN devices in your home network and
connect them together into a secure network using
the dLAN 500 WiFi – this could be considered the
counterpart to the local devolo dLAN Cockpit soft-
ware (see 5.3 dLAN Cockpit).
In addition, you can also use dLAN Cockpit App to
access the configuration interface for the
dLAN 500 WiFi and to change settings in the WLAN
and dLAN network (see 6 Network configuration).
햲 After you have integrated the dLAN 500 WiFi into
your home network as described in Chapter 4.4
Connecting the dLAN 500 AV Wireless+ and
have downloaded dLAN Cockpit App, you can get
to start menu just by tapping on dLAN Cockpit.
햳 In order to connect the dLAN 500 WiFi to your
smartphone or tablet PC, select My dLAN.
햴 As soon as your smartphone or tablet is connected
to the dLAN 500 WiFi, all of the adapters found in
the network appear with a picture and corre-
sponding name.
The menu in dLAN Cockpit App automatically
adjusts to the orientation (horizontal/vertical)
of the smartphone or tablet P.
If your smartphone or tablet switches to power
saving mode, the previously displayed view is
shown again when you activate the screen
again.
5.2.1 Overview page
You can page through the list of adapters by swiping
across the screen (left/right or up/down).
The house icon displays the connection over
dLAN.
The WLAN icon displays the connection over
WLAN.
The bar graph reflects the connection quali-
ty. The data rate is displayed in Mbps. Tap-
ping on a respective adapter allows you to
read the transfer rate for another device from
the selected adapter's point of view.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
