Introduction 9
devolo dLAN pro 1200 DINrail
2.2.1 Functions
쎲 Direct installation in the control cabinet or power
distribution box
쎲 Optional: three-phase network connection for
optimal network coverage
쎲 Remote management via the
dLAN AVpro manager management software
쎲 Integrated Quality-of-Service functions (QoS) for
automatic data prioritisation
쎲 Quality indicator LED for determining broadband
status
쎲 Gigabit-Ethernet port with Auto MDI/X
쎲 PE connection
쎲 Master/slave or peer-to-peer architecture
쎲 Segments possible with up to 63 slaves per master
쎲 Data transmission with a range up to 400 metres
in the power grid
쎲 Powerful 128-bit AES security for securing data
transmission against unauthorised access
쎲 Further extensive configuration options (notching,
output power etc.)
2.2.2 Ports
Line connections (Fig. 1)
This is where you connect the conductors to the corre-
sponding line connections.
NOTE:
Single-phase connection: Neutral conductors and ex-
ternal conductors are connected to terminals N and L1.
Three-phase connection: Neutral conductors and
three external conductors are connected to terminals
N, L1, L2 and L3. The device is supplied with power via
terminals N and L1.
PE connection: Connecting the earth wire to the PE
terminal is optional.
The permitted conductor cross-section for connection
to the terminals is 0.18 mm² to 6 mm².
Ethernet connection (Fig. 1)
This is where you connect the dLAN pro 1200 DINrail
via an Ethernet cable to the intelligent power meter
(MUC) or another Ethernet device (e.g. Internet access
device).
