devolo dLAN pro 1200+ PoE
2.3.3 dLAN MDU
In an MDU network (MDU: Multiple Dwelling Unit), the
connected network nodes are linked as slaves to a
master and, together with the master, form a logical
dLAN pro network segment. Each slave sends data
only to its master. At the technical level, communica-
tion between the slaves of the MDU dLAN is not possi-
ble. The masters of the MDU dLANs are interconnected
via Ethernet switches. Thus MDU dLANs are ideally
suited for floor-by-floor networking (such as in hotels).
Room 1
Room 2 Room 3
Room 4
Fig. 4
