DESCRIPTION OF THE TOOL
OPERATING CONTROL
The power tool is intended for hammer drilling in concrete, brick and stone. It is likewise
suitable for drilling without hammer in wood, metal, ceramic, plastic and chiseling. Do not use
machine, tools and chargers for works other than those for which they are designed for! All
other applications are expressly ruled out.
1. MAIN PARTS
1. Locking sleeve
2. LED worklight
3. Function selector
4. Battery pack
5. Battery release button
6. Forward/reverse switch
7. On/off trigger switch
NOTE
1 Attach the battery pack on the charger for short charging to resume the battery, when the battery
pack is protected as the redundant current and high temperature.
2 For continuous long operation, the tool may be hot; cool it down to appropriate temperature before
reuse, otherwise, may damage the tool.
5401-Li-20RH
5401-Li-20RH/N
1
2
5
3 6 7
4
