ENGLISH
11
• Proceed as described for hammer drilling.
WARNING: Never use standard chucks
in the hammer drilling mode.
Screwdriving (fi g. A)
• Set the mode selector switch (4) to the “rotary
drilling” position.
• Select the direction of rotation.
• Depending on your tool, follow either of the
following instructions:
– Insert the special SDS-plus® screwdriving
adaptor for use with hexagonal screwdriver
bits (D25102(K)/D25103K/D25203K).
– Replace the tool holder with the chuck
(D25104K).
• Insert the appropriate screwdriver bit. When
driving slotted head screws always use bits with
a finder sleeve.
• Gently press the variable speed switch (1) to
prevent damage to the screw head. In reverse
(LH) rotation the tool speed is automatically
reduced for easy screw removal.
• When the screw is flush with the workpiece,
release the variable speed switch to prevent
the screw head from penetrating into the
workpiece.
D25103K/D25104K/D25203K
Chipping and chiselling (fi g. A)
• Set the mode selector switch (4) to the
“hammering only” position.
• Insert the appropriate chisel and rotate it by
hand to lock it into one of 51 positions.
• Adjust the side handle (9) as required.
• Switch on the tool and start working.
• Always switch off the tool when work is finished
and before unplugging.
WARNING:
• Do not use this tool to mix or pump
easily combustible or explosive fluids
(benzine, alcohol, etc.).
• Do not mix or stir inflammable liquids
labelled accordingly.
Various types of SDS-plus® drill bits and chisels are
available as an option.
MAINTENANCE
Your DEWALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning
• This machine is not user-serviceable. Take the
tool to an authorised DEWALT repair agent
after approximately 40 hours of use. If problems
occur before this time contact an authorised
DEWALT repair agent.
• The tool will automatically switch off when the
carbon brushes are worn.
Lubrication
Your power tool requires no additional lubrication.
Accessories and attachments used must be
regularly lubricated around the SDS-plus® fitment.
Cleaning
WARNING: Blow dirt and dust out of
the main housing with dry air as often
as dirt is seen collecting in and around
the air vents. Wear eye protection when
performing this procedure.
WARNING: Never use solvents or
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.
Optional accessories
WARNING: Since accessories, other
than those offered by DEWALT, have
not been tested with this product, use
of such accessories with this tool could
be hazardous. To reduce the risk of
injury, only DEWALT recommended
accessories should be used with this
product.
